TP-Link TL-SG1016D User Manual
8-, 16-, 24- port gigabit switch
Hide thumbs
Also See for TL-SG1016D:
- User manual (3 pages) ,
- Installation manual (32 pages) ,
- Installation manual (32 pages)
Subscribe to Our Youtube Channel
Related Manuals for TP-Link TL-SG1016D
Summary of Contents for TP-Link TL-SG1016D
-
Page 1: User Guide
User Guide TL-SG1008 8-Port Gigabit Switch TL-SG1016D 16-Port Gigabit Switch TL-SG1024D 24-Port Gigabit Switch Rev: 2.0.1 7106503502... - Page 2 Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.
-
Page 3: Fcc Statement
FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 4: Table Of Contents
CONTENTS Package Contents ........................1 Chapter 1 Product Introduction ..................... 2 Product Overview ....................2 Features ........................ 2 Chapter 2 Identifying External Components ............... 3 Front Panel ......................3 Rear Panel ......................3 Chapter 3 Installation ......................4 Precautions ......................4 Installation ...................... -
Page 5: Package Contents
Mounting screws and two “L” planks Note: Make sure that the package contains the above items. If any of the listed items are damaged or missing, please contact with your distributor. TL-SG1016D and TL-SG1024D do not include mounting screws and two “L” planks. -
Page 6: Chapter 1 Product Introduction
Chapter 1 Product Introduction This chapter describes the features of the TL-SG1008/TL-SG1016D/TL-SG1024D Switch. 1.1 Product Overview The TL-SG1008/TL-SG1016D/TL-SG1024D Switch provides you with a high- performance, low-cost, easy-to-use, seamless and standard upgrade to boost your old network to 1000Mbps. Increase the speed of your network server and backbone connections make Gigabit a reality. -
Page 7: Chapter 2 Identifying External Components
Chapter 2 Identifying External Components This Chapter describes the front panel, rear panel and LED indicators of the Switch. TL-SG1008/TL-SG1016D/TL-SG1024D just differ in the number of LED indicators and ports and all figures in this guide are of TL-SG1008. 2.1 Front Panel The front panel of TL-SG1008 consists of switch model, switch LED indicators, and 8 10/100/1000Mbps RJ-45 ports. -
Page 8: Chapter 3 Installation
cable of AC cord or with Ground Cable. For detail information, please refer to section 3.3 Connect to Ground. AC Power Socket: Connect the female connector of the power cord here, and the male connector to the AC power outlet. Please make sure the voltage of the power supply meets the requirement of the input voltage. -
Page 9: Desktop Installation
Caution: Please unplug the power cord before installing or removing the Switch. 3.2.1 Desktop Installation To install the Switch on the desktop, please follow the steps: 1) Set the Switch on a flat surface strong enough to support the entire weight of the Switch with all fittings. - Page 10 Figure 3-3 Mounting Switch 3) Connect the Switch to network devices. 4) Supply power to the Switch with the provided power cord. Note: TL-SG1016D and TL-SG1024D do not support rack installation.
-
Page 11: Connect To Ground
3.3 Connect to Ground Connecting the Switch to ground is to quickly release the lightning over-voltage and over-current of the Switch, which is also a necessary measure to protect the body from electric shock. In different environments, the Switch may be grounded differently. The following will instruct you to connect the Switch to the ground in two ways, connecting to the Grounding Bar or connecting to the Ground via the power cord. -
Page 12: Power On
3.4 Power on The TL-SG1008/TL-SG1016D/TL-SG1024D Switch is powered by an AC Power Supply. Connect the Switch and power outlet by power cord. Powering on the Switch, it will be automatically initialized and the LED indicators should respond as... -
Page 13: Appendix A: Specifications
Appendix A: Specifications General IEEE802.3 10Base-T Standards IEEE802.3u 100Base-TX IEEE802.3ab 1000Base-T Topology Star Protocol CSMA/CD Ethernet: 10Mbps (Half Duplex), 20Mbps (Full Duplex) Data Transfer Fast Ethernet: 100Mbps (Half Duplex), 200Mbps (Full Rate Duplex) Gigabit Ethernet: 2000Mbps (Full Duplex) 10Base-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100 STP (maximum 100m) 100Base-TX: UTP category 5, 5e cable (maximum Network Media... - Page 14 Environmental and Physical Operating Temperature 0℃~40℃ (32℉~104℉) Storage Temperature -40℃~70℃ (-40℉~158℉) Operating Humidity 10%~90% non-condensing Storage Humidity 5%~90% non-condensing...
-
Page 15: Appendix B: Troubleshooting
Make sure the connected device is turned on and working well. The cable must be less than 100 meters long(328 feet). Appendix C: Contact Information For help with the installation or operation of the TP-LINK TL-SG1008/TL-SG1016D/ TL-SG1024D Switch, please contact us. E-mail: support@tp-link.com...
