- Page 1 Business Networking Solution Installation Guide Omada Easy Managed Switch...
- Page 2 Conventions • Some models featured in this guide may be unavailable in your country or region. For local sales information, visit https://www.tp-link.com/business-networking/. • The figures in Chapter 2, Chapter 3 and Chapter 4 are for demonstration purposes only. Your switch may differ in appearance from that depicted.
- Page 3 Contents Chapter 1 Introduction ——————————— 01 Product Overview ............01 Appearance ...............01 Chapter 2 Installation ——————————— 05 Package Contents ............05 Safety Precautions ............05 Installation Tools ..............07 Product Installation ............07 Chapter 3 Connection ——————————— 09 Ethernet Port ..............09 SFP Slot ................09 Verify Installation .............09 Power On ................10 Initialization ................10 Chapter 4 Configuration ——————————...
- Page 4 ES220GMP/ES228GMP is also a Power Sourcing Equipment (PSE*). Some of the RJ45 ports on the switch support Power over Ethernet (PoE*) function, which can automatically detect and supply power to those powered devices (PDs*) complying with IEEE 802.3af and IEEE 802.3at.
- Page 5 Omada Easy Managed Switch The front panel of ES220GMP is shown as the following figure. Figure 1-3 Front Panel of ES220GMP LEDs LED Mode Reset 10/100/1000 Mbps SFP Slot Switch Button RJ45 Port The front panel of ES228GMP is shown as the following figure.
- Page 6 LED is on) Off: No device is linked to the corresponding port. Note: Speed or PoE for port 1–16 of ES220GMP and port 1–24 of ES228GMP. Green On: The port is supplying power normally. Green Flashing: The supply power exceeds the correponding port's maximum power.
- Page 7 The switch already comes with lightning protection mechanism. You can also ground the switch through the PE (Protecting Earth) cable of AC cord or with Ground Cable. For detailed lightning protection measures, refer to the Lightning Protection Guide: https://www.tp-link.com/us/configuration-guides/ lightning_protection_guide/.
- Page 8 Omada Easy Managed Switch Chapter 2 Installation Package Contents Make sure that the package contains the following items. If any of the listed items is damaged or missing, please contact your distributor. One Power Cord One Switch Mounting Brackets, Screws Installation Guide and Feet *Images are for demonstration only.
- Page 9 To find out the best temperature and humidity conditions for the device, check the following table. Environment Temperature Humidity -5 °C to 50 °C(For ES220GMP) Operating 0 °C to 45 °C (For ES228GMP) 10% to 90%RH Non-condensing 0 °C to 50 °C (For other switches) Storage -40 °C to 70 °C...
- Page 10 Use the signal SPD (Surge Protective Device) when wiring outdoor. ■ Note: For detailed lightning protection measures, refer to the Lightning Protection Guide: https://www.tp-link.com/us/configuration-guides/lightning_protection_guide/. Installation Site When installing the device on a rack or a flat workbench, attach much importance to the following items: The rack or workbench is flat, stable, and sturdy enough to support the weight of 5.5 kg at least.
- Page 11 Omada Easy Managed Switch Figure 2-1 Desktop Installation Feet Bottom of the Device Notch Rack Installation ■ To install the device in an EIA standard-sized, 19-inch rack, follow the instructions described below: 1. Check the efficiency of the grounding system and the stability of the rack. 2.
- Page 12 Omada Easy Managed Switch Chapter 3 Connection Ethernet Port Connect an Ethernet port of the switch to the computer by RJ45 cable as the following figure shows. Figure 3-1 Connecting the RJ45 Port RJ45 Port RJ45 Cable SFP Slot The following figure demonstrates the connection of SFP module to an SFP slot. Figure 3-2 Inserting the SFP Module SFP Slot...
- Page 13 2. After about 10 seconds, all LED indicators will turn green, and then all LED indicators except the Power LED will turn off. For ES220GMP/ES228GMP: 1. The PWR LED indicator lights on all the time. All other LED indicators keep off.
- Page 14 Note: ES216G, ES224G, ES220GMP and ES228GMP support both Standalone Mode and Controller Mode. When the switch is changed from Standalone Mode to Controller Mode, you should reconfigure the switch.
- Page 15 Launch a web browser and enter https://omada.tplinkcloud.com in the address bar. Enter your TP-Link ID and password to log in. Click + Add Controller and choose Hardware Controller to add your controller. Then you can further configure the controller.
- Page 16 Make sure that Cloud Access is enabled on your controller and your controller has been bound with your TP-Link ID. On the Omada Controller’s web page, go to Settings > Cloud Access to enable Cloud Access and bind your TP-Link ID. If you have set it up in the quick setup, skip this step.
- Page 17 Omada Easy Managed Switch Appendix A Troubleshooting Q1. What could I do if I forgot the username and password of the switch? Press the Reset button for at least 5 seconds to reset the system. The system will be reset to the factory default settings, and the default login user name and password are both admin.
- Page 18 ES224G: Power, Link/Act, 1000Mbps LEDs ES220GMP: PWR, SYS, PoE MAX, FAN, Speed or PoE, Speed, PoE, SFP ES228GMP: PWR, SYS, PoE MAX, FAN, Speed or PoE, Speed, PoE, SFP -5 °C to 50 °C (23 °F to 122 °F) (For ES220GMP) Operating Temperature 0 °C to 45 °C (32 °F to 113 °F) (For ES228GMP)
- Page 19 EU declaration of conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863. The original EU declaration of conformity may be found at https://www.tp-link.com/en/support/ce/...
- Page 20 To ask questions, find answers, and communicate with TP-Link users or engineers, please visit https://community.tp-link.com/business to join TP-Link Community. For technical support, the user guide and other information, please visit https://www.tp-link.com/support/download/?type=smb, or simply scan the QR code. ©2024 TP-Link 7106511600 REV2.0.0...
