AVPro Edge AC-EX100-UHD-KIT-P Quick Start Manual

100m hdbaset kit

AC-EX100-UHD-KIT-P

100m HDBaseT Kit

Quick Start Guide

This long range (100m, 330ft. up to 4K) is unrivaled when it comes to the features

it comes with. these extenders are designed to be a true problem solver. When

the situation requires more power, distance, added Ethernet and reverse power

or control, the B.A.E has it covered. Using the most powerful HDBaseT technology

on the market, this product is sure be a robust long lasting part of your

infrastructure.

This quick start guide

will be going through:

• SEt up

• RS232 COnfiguration

• EDid

• Troubleshooting

SET UP

1. Connect a cat cable from the transmitter to the receiver via the hdbt

ports

2. Plug the power into either the transmitter or reveiver. PoE Direction is

set by the dip switch on the Tx and Rx. You are selecting whether you want

the unit to RECEIVE PoE or SEND PoE.

3. Connect your source (4k source, gaming console, blueray player) to the

transmitter via hdmi

4. Connect your display via hdmi

Table of Contents

Do you have a question about the AC-EX100-UHD-KIT-P and is the answer not in the manual?

Page 1 AC-EX100-UHD-KIT-P 100m HDBaseT Kit Quick Start Guide This long range (100m, 330ft. up to 4K) is unrivaled when it comes to the features it comes with. these extenders are designed to be a true problem solver. When the situation requires more power, distance, added Ethernet and reverse power or control, the B.A.E has it covered.
Page 2 RS-232 Configuration RS-232 can be used to pass control signals bi-directionally to & from any RS-232 compatible device. In order to connect your computer to the extender by rs232 you need to make your own cable with one end a phoenix connector and the other end a rs-232 port.
Page 3 Advanced EDID Management is a unique and extremely powerful feature of the AC-EX100-UHD-T. EDID problems are common in todays installations and this feature overcomes that problem TRANSMITTER EDID Settings Receiver Edid Settings ROTARY SWITCH POSITION: Rotary switch Position: 0-4k60 420 3D 8ch - FACTORY DEFAULT 0 - 4k60 420 3D 2ch 1-4k60 420 3D 6ch 1 - 4k60 420 3D 6ch...
