- Page 1 Intermediate position module SLG-Z-... (en) Operating instructions 8074758 2017-10b [8074760]...
- Page 2 ............... . . Festo SLG-Z-... 2017-10b...
-
Page 3: Operating Parts And Connections
SLG-Z-... Intermediate position module type SLG-Z-...English Documentation on the product For all available product documentation è www.festo.com/pk Operating parts and connections Connecting thread for compressed air Stop lever with stop Grooves for proximity switches Toothed profile for approximate positioning Centring holes (for positioning without fastening rail type SLG-...-S-...) - Page 4 (e.g. in conjunction with the intermedi ate position sets with a slide unit type SLG-...). Within the permitted loading limits, the intermediate position module also func tions as a stop. Festo SLG-Z-... 2017-10b English...
-
Page 5: Conditions Of Use
If dirt is not removed, the lever may only swivel with difficulty. Fig. 5 Slowly pressurize the complete system. To do this use start-up valve type HEL-..Use the product in its original state. Un authorized modification is not permitted. Fig. 6 Festo SLG-Z-... 2017-10b English... - Page 6 When retrofitting an existing slide unit type SLG-... , you can use the shock ab sorbers of the slide unit. Lift these out with a screwdriver and push them into the cushioning support (see Fig. 9). Fig. 9 Festo SLG-Z-... 2017-10b English...
- Page 7 (D) and tighten with screws in all the fastening holes. The supporting surface must be level (see operating in structions for type SLG-...). The tightening torques are shown in the SLG-S-... table below: Fig. 12 Fig. 13 Festo SLG-Z-... 2017-10b English...
- Page 8 (see Fig. 17). Fig. 16 SLG-Z-... 8-... 12-... 18-... Minimum distance – for swivelling the stop lever X 23 mm 23 mm 31 mm – for thescrew connection X 16 mm 16 mm 16 mm Fig. 17 Festo SLG-Z-... 2017-10b English...
- Page 9 S Make sure that the slide of the linear drive is outside the swivel range when the stop lever moves in (e.g. by means of a control delay circuit). The swivel-in speed of the stop lever exceeds the slide speed of the slide unit type SLG-..Festo SLG-Z-... 2017-10b English...
- Page 10 S Make sure that: – nobody can place his/her hand in the positioning range of the stop lever. – there are no objects in the position- ing range of the stop lever. Fig. 22 Festo SLG-Z-... 2017-10b English...
- Page 11 6. Accelerate the work load in steps until the operating speed is reached. Please refer to your application for these speeds. The slide of the linear drive must not strike hard against the intermediate posi tion module type SLG-Z-..Festo SLG-Z-... 2017-10b English...
-
Page 12: Operation
Take into account the fact that the end position will change after long periods of operation due to the continuous deformation of the rubber buffer. With diagonal or vertical fitting of the module. Use the cushioning variant with shock absorber type YSRG-..Festo SLG-Z-... 2017-10b English... -
Page 13: Care And Maintenance
Permitted cleaning agents are: – soap suds (max. 60 °C) – all non-abrasive agents. Dismantling and repairs Dismantling Exhaust the complete system and the module. If required: Return the SLG-Z-... to our repair service for overhaul. Festo SLG-Z-... 2017-10b English... -
Page 14: Eliminating Faults
Incorrect type of proximity Use only proximity switches of switched used type SME/SMT-10-... Proximity switch defective Replace proximity switch Ferritic parts in vicinity of Use parts made of non- proximity switch magnetic materials Fig. 27 Festo SLG-Z-... 2017-10b English... -
Page 15: Technical Specifications
- 10 ... max. + 60 °C Materials Housing: Al (anodized) Toothed rod: Pinion: Screws, sliding block: Seals: Rubber buffer: Weight (SLG-...-Z..) 33.5 g 33.5 g 75 g Fig. 28 At 6 bar and T = 20 °C Festo SLG-Z-... 2017-10b English... - Page 16 Copyright: Festo SE & Co. KG Ruiter Straße 82 73734 Esslingen Germany Phone: +49 711 347-0 Fax: +49 711 347-2144 E-mail: Reproduction, distribution or sale of this document or communica service_international@festo.com tion of its contents to others without express authorization is prohibited.
