Pneumatic two-hand control unit

Advertisement

Quick Links

Einbau und Inbetriebnahme
nur von autorisiertem Fachpersonal,
gemäß Bedienungsanleitung.
Fitting and commissioning to be
carried out by qualified personnel
only in accordance with the operating
instructions.
Es bedeuten/Symbols:
Warnung
Warning, Caution
Hinweis
Note
Recycling
Recycling
Zubehör
Accessories
0010a
Bedienungsanleitung
Pneumatischer
Zweihandsteuerblock
Typ ZSB(D)-1/8
Sicherheitsbauteil nach ... *)
2 (A)
1 (P )
1
1
3 (R)
Operating instructions
Pneumatic
two-hand control unit
Type ZSB(D)-1/8
Safety component as per ... *)
*)
... EN 574
Typ III A
Type III A
3 (R)
*)
... EN 574
Typ III B
1 (P )
Type III B
2
2
Schaltbild siehe Bild 4
Const. drawing see Fig. 4
D/GB 1
