  • Page 1 Radiophone Helsinki RTM 127 Operating instructions...
  • Page 2 Erklärung der Positions-Nummern siehe Kurzanleitung / Refer to the Quick Reference for an explanation of the operating elements (PAC) Fernbedienung RCT 07 (Option) Remote control RCT 07 (optional)

  • Page 3: Table Of Contents

    Contents (Radio, CD changer - optional) Important information ... 73 Safety standards ... 73 General information ... 73 Effects of RF (radio frequency) energy ... 73 Safety information ... 73 Traffic safety ... 73 Using the telephone while driving ... 73 Using the telephone in critical areas .
  • Page 4 Contents (Radio, CD changer - optional) Angle ... 93 Ignition timer ... 93 Change code ... 93 User mode ... 93 Reset ... 93 Overview of the DSC default settings (Setup) ... 94 DSC MENU – Radio ... 94 Radiotext ... 94 Loudness ...
  • Page 5 Contents (Telephone) Telephone operation ... 98 General information ... 98 Emergency calls ... 98 PIN code (Personal Identification Number) ... 98 Insert the SIM card/enter your PIN code ... 98 Reactivating the SIM card ... 98 Make your first telephone call ... 99 GSM emergency calls ...
  • Page 6 Contents (Telephone) Network selection ... 121 Available networks ... 121 Search method ... 121 Preferred networks ... 122 Call meters ... 122 Call forwarding (with a practical example) ... 123 In which situation should a call be forwarded? ... 123 Forward calls, PC data, faxes ...

  • Page 7: Important Information

    Important information Safety standards The mobile telephone has been manufac- tured in accordance with all of the applica- ble radio frequency (RF) safety standards and recommendations determined by the government offices and organisations re- sponsible (e.g. the VDE standard DIN- 0848).

  • Page 8: Using The Telephone In Critical Areas

    Important information • Stop at a safe place before using the telephone. • If otherwise unavoidable: Use only hands-free operation if you have to use the telephone while you are driving. Traffic safety always has the highest priori- Using the telephone in critical areas Always switch off the mobile telephone in areas where it is forbidden to use a mobile...

  • Page 9: Notes On Connecting A Cd Changer, Amplifier, Voice Control System Or Infrared Remote Control Unit

    Radiophone from the steering wheel. The operating functions are described in the Quick References. Handset (telephone receiver) Using the Blaupunkt handset 7 607 570 512 it is possible to place telephone calls with or without the hands-free function. The system will switch automatically from hands-free to handset operation when the handset is removed from the cradle.

  • Page 10: Keycard And Sim Card

    KeyCard and SIM card KeyCard Basic information One KeyCard is included with the Radio- phone. The car radio can also be operated with a second ”trained” KeyCard or with one of up to 30 “trainable” SIM cards. Using the KeyCard it is possible to activate the following operating modes: Radio, CD changer (optional), AUX, tele- phone emergency call.

  • Page 11: Select The Language For The Display

    KeyCard and SIM card Select the language for the display At the factory the texts for the display are set to English. You can display the texts in other languag- es if you wish. • Press DSC/OK. Two menu items will appear in the display: Setup and Ra- dio.

  • Page 12: Dsc Learn Mode

    KeyCard and SIM card If necessary, refer to “How to enter a name/text “. • Press DSC/OK. • Enter the PIN code and press DSC/ After “CODE OK”, the display shows e.g. “SIM-CARD 23 ACCEPTED” (i.e. this is the 23rd SIM card you have trained).

  • Page 13: Care Of Your Keycard/Sim Card

    Care of your KeyCard/SIM card In order to ensure that the card always func- tions correctly, the contacts must be free of any foreign particles. Avoid touching the contacts with your fingers. Do not leave the cards in direct sunlight. If necessary, clean the card contacts using a cotton swab dipped in rubbing alcohol.
  • Page 14 Quick reference for radio and CD changer (optional) operation Alter the volume Turn the knob to alter the volume. The setting selected will appear in the dis- play. When the Radiophone is switched on, it will play at a preset volume (VOL- UME FIX).
  • Page 15 Quick reference for radio and CD changer (optional) operation 6 SMS It is possible to read any SMS messag- es as they are received, regardless of the operating mode selected. 7 PaX oder PAC (Personal Access) Use this button to directly access a certain function which has been pro- grammed previously.
  • Page 16 Quick reference for radio and CD changer (optional) operation CD changer operation (optional) MIX CD The tracks of a CD will be played back in random order. The following CDs will also be selected at random. MIX OFF The MIX function is switched off. Press MIX until the desired function appears in the display.
  • Page 17 Quick reference for radio and CD changer (optional) operation ? Rocker switch Radio operation Search Down << / >> Up or down in increments (for FM only when AF is switched off) For FM only: << / >> Scroll through the station broad- casting network when AF is switched on e.g.

  • Page 18: Select Operating Mode

    If you have inserted a magazine containing no CDs, the display shows “NO CD”. An auxiliary source cannot be selected un- less a Blaupunkt changer has been connect- ed to the system. ”AUXILIARY SOURCE ON” must be set in the DSC menu.

  • Page 19: Radio Operation With Rds

    Radio operation with RDS (Radio Data System) The Radio Data System offers you added convenience when listening to FM radio sta- tions. More and more radio stations have begun to broadcast RDS information along with their regular programs. As soon as a program has been identified, the station name including a regional identi- fier, if applicable, will appear in the display, for example, NDR1 NDS (regional program...

  • Page 20: Manual Tuning With

    Radio operation with RDS (Radio Data System) Search Down << / >> Up/Down in increments (for FM only when AF is switched off) Manual tuning with << / >> You can also tune in a station manually. Important: AF must be switched off (i.e. the ”AF” or ”REG”...

  • Page 21: Automatically Store The Stations With The Strongest Reception Using Travelstore

    Radio operation with RDS (Radio Data System) briefly in the display if you are using the same memory bank. Automatically store the stations with the strongest reception using Travelstore You can automatically store the nine most powerful FM stations in your current recep- tion area in the “FMT”...

  • Page 22: Radiotext

    Radiotext This is an RDS function which transmits text from the radio station selected. Depending on the radio station, these texts will vary in content, e.g. short news reports, program information, advertising. For further information, refer to “Program- ming with DSC – Radio”. Traffic program station reception with RDS-EON The abbreviation “EON”...

  • Page 23: Switch Off The Warning Beep

    You will also hear this warning beep if you press a station preset button for a radio sta- tion which does not broadcast the TP sig- nal. Switch off the warning beep a) Tune into another station providing traffic information: •...

  • Page 24: Enter Cd Names

    CD changer operation (optional) Enter CD names You can enter names for up to 99 CDs. If you insert a CD, its name will appear in the display (e.g. VIVALDI) provided that you have entered a name for it in the DSC menu –...

  • Page 25: Pax (Pac) Memory

    Following this, the next CD will be selected at random and played, etc. Switch MIX on/off: • press MIX/ briefly. PaX (PAC) memory In radio or telephone mode, the PaX mem- ory allows you to access one certain func- tion which has been programmed previous- ly.

  • Page 26: Programming With Dsc - Setup

    Programming with DSC – DSC menu – Setup (basic equipment settings) • Press to select “Setup”. • Press OK. A maximum of four menu items will appear in the display. Press to select the menu item you wish to alter. Language KeyCard LED Beep...

  • Page 27: Keycard Led

    Programming with DSC – Setup KeyCard LED You can choose between LED ON or LED OFF. If you select LED ON, the KeyCard tongue will flash as an additional anti-theft device when the unit has been switched off and the KeyCard removed. BEEP Confirmation beep following functions which require you to press the button for longer...

  • Page 28: Dsc Menu – Radio

    Overview of the DSC default set- tings (Setup) Learn card – Card list – Learn mode Menu Plus* Language Automatic KeyCard LED Beep Key tones Vario Colour green Brightness D approx. 90 % N approx. 60 % Angle Middle Ignition timer 00 min.

  • Page 29: Volume Fix

    Programming with DSC – Radio VOLUME FIX Allows you to set the volume at which the unit switches on. Use << / >> to set the desired volume. If ”Last Volume” is selected, the car radio will switch on at the volume level which was last set before it was switched off.
  • Page 31 Telephone operation...

  • Page 32: Telephone Operation

    Telephone operation General information Using the Radiophone, you can make the same telephone calls as you can with a cel- lular phone. Important: You must be located in an area serviced by the GSM radio network and have the ac- cess privileges provided by a valid SIM card.

  • Page 33: Make Your First Telephone Call

    Telephone operation Make your first telephone call When the telephone is ready to operate, an antenna symbol will appear in the display (must not flash). A trained SIM card must be inserted in the unit correctly. If the equipment is not cur- rently in the telephone mode •...

  • Page 34: Quick Telephone Reference

    Quick telephone reference 1 On/Off The set must be switched on before it is possible to use the telephone. Volume Adjusts the volume while using the “hands-free” function Adjusts the TA volume while using the “hands-free” function Adjusts the volume of the current ring tone.
  • Page 35 Quick telephone reference Press the corresponding key for ap- prox. 2 seconds. To use one-touch-dialling to call one of the first nine phone book numbers stored on the SIM card: Press , then press the corresponding key for approx. 2 seconds. To enter names, refer to the section on “How to enter a name/text”.
  • Page 36 Quick telephone reference Display during a telephone call d e f g DSC menu during telephone mode - Indicates connection to home network - Indicates connection to a roaming network If the antenna symbol is flashing, the telephone user has not got access privileges to the network currently avail- able.
  • Page 37 Quick telephone reference Remote control: To display the telephone-book menu in alphabetical order: Press ME briefly. To display the telephone-book menu in the numerical order of the entries: Press ME for approx. 2 seconds. Press to make your selection and to start dialling.

  • Page 38: Using The Telephone

    Using the telephone All of the telephone functions can be oper- ated using a trained SIM card. • With the card tongue protruding, insert the trained SIM card into the slot with the contact surface facing up. • Switch the unit on. If you have not yet trained a SIM card, refer to “Train or delete KeyCards/SIM cards”.

  • Page 39: Dial A Telephone Number

    Using the telephone Dial a telephone number The telephone mode must be switched on. Always use the area code for the number you are dialling, even if it is a local number. Manual dialling • Dial the number using the number keys.

  • Page 40: From The Telephone Book

    Using the telephone . . . from the telephone book • Press ME. • to select “Find name” or “Find pos”. • Confirm your selection by pressing • Use the selection buttons to enter up to the first three letters in the name. •...

  • Page 41: Broker's Call/Hold

    Using the telephone How it works You are still talking on the telephone to the first party. You hear the call waiting signal. To refuse the call: • Press CL. To answer the waiting call: • Press OK. The first party will be put on hold (cannot join in on the second call).

  • Page 42: International Calls

    0049 Germany City area code: 05121 Hildesheim Teleph. number: 49 ..Blaupunkt You enter: +49512149 ..Tip: Enter the country access code for all of the telephone numbers you save in the memo- How to receive calls Callers from your home country merely dial the usual number for your mobile phone.

  • Page 43: Make Telephone Calls Using The Handset (Accessory)

    Using the telephone – available networks – call forwarding – telephone book/find entry by name • Press PaX or PAC briefly. Select the function: • Press PaX or PAC for approx. 1 sec- ond. A list of the functions you can select directly will appear in the display.

  • Page 44: Phone Book Menu

    Select function << / >> Adjust setting Adjust: Press << / >> to adjust the setting in the dis- play and press OK to confirm your change. Cancel: • Press CL and any changes made will not be saved. Save/confirm: •...

  • Page 45: Enter Letters/Characters

    Programming with DSC – Phone book Enter letters/characters Example “O” = press key 6 three times. The keys are sequence keys, i.e. press the keys repeatedly to call up the letters allo- cated to this key. You can use these keys to enter the follow- ing characters: 1 1 (blank) .

  • Page 46: Find An Entry By Position

    Programming with DSC – Phone book Find an entry by position • Press to select “Find pos.” and press OK. • Enter the position number using the numbers keys and press OK. • Press to select a different entry. To dial the telephone number automatical- •...

  • Page 47: Add Entry

    Programming with DSC – Phone book Add entry • Press to select “Add entry” and press OK. • Press to select the memory bank for the entry, e.g.: “SIM card” or “Phone” and press OK. • Enter the new telephone number and press OK.

  • Page 48: Show My Phone Number

    0 to 63. Handset (volume) This menu item will not appear unless a Blaupunkt handset has been connected to the system. Press << / >> to adjust the volume of the handset from 1 to 10. Remove the handset...

  • Page 49: Automatic Answer

    Programming with DSC – Setup Automatic answer The telephone is able to answer incoming calls automatically. • Press to select “Auto. answer” and press OK. • Press to select the setting you want and press OK. – The automatic answer function is switched off.

  • Page 50: Aoc Parameters (Advice Of Charge)

    Programming with DSC – Setup Press to select the position for your own phone number. Press OK and enter your own phone number and press OK again. Enter a name if de- sired and press OK. The number will be saved in the memory.

  • Page 51: Pin-Code

    Programming with DSC – Setup PIN-code Switches on/off and alters the PIN code. • Press to select “PIN code” and press OK. Ring. tones My number AOC param. Audib. timer PIN-code Press OK to switch between Off, On, Change. An arrow will indicate the setting selected last.

  • Page 52: Ta (Traffic Announcement) During A Telephone Call

    Programming with DSC – Setup The alarm will be activated five times when an incoming call is detected. To protect the car battery, the set will switch off automatically after one hour. This function can be switched on again for one hour by pressing the on/off button on the set.

  • Page 53: Call Menu

    Programming with DSC – Call menu Use this menu to select the settings for net- work operation. • Press to select “Call”. • Press OK. Call meters Forwarding Barring Phone lock User group A maximum of four menu items will appear in the display.

  • Page 54: Read New Messages

    Programming with DSC – Call Menu Read new messages • Press to select “Input” and press If there is more than one message, press to select the message you want to read and press OK. Press to move through the message line by line forwards or backwards.

  • Page 55: Parameters

    Programming with DSC – Call Menu Parameters • Press to select the function de- sired and press OK. “VALIDITY”: Here you can determine for how long your network operator should try to send a mes- sage. The standard value is one day. Use the numbers keys to set the value from 1 to 7.

  • Page 56: Preferred Networks

    Programming with DSC – Call Menu If the antenna symbol is flashing, you do not have access privileges to the network cur- rently connected. You can place emergency calls only. Preferred networks • Press to select “Pref. list” and press OK. •...

  • Page 57: In Which Situation Should A Call Be Forwarded

    Programming with DSC – Call Menu “Reset” The timer for the time and charges is set to zero. You must enter the access code to do a reset. “During call” You can select whether or not you want the call timer and charges displayed during calls. Call forwarding (with a practical example) You can forward incoming calls to another...

  • Page 58: A Practical Example Of Call Forwarding

    Programming with DSC – Call Menu – “Status” Press to display the current selec- tion: “not registered” if call forwarding has not been activated or “registered” (plus call forwarding number) if call forwarding has been ac- tivated. – “Clear” Call forwarding will be deleted immedi- ately.

  • Page 59: Call Barring

    Programming with DSC – Call Menu Call barring It is possible to block incoming/outgoing calls. You will require a password from your network operator in order to set up call bar- ring. • Press to select “Barring” and press OK. Call meters Forwarding Barring...

  • Page 60: Enter Data For Call Barring

    Programming with DSC – Call Menu Enter data for call barring Each type of call barring has the same processing list for speech, data and fax: – “Status” Press to display the current selec- tion: “not registered” if call barring has not been activated or “registered”...

  • Page 61: Specifications

    Specifications Amplifier Output power: 4 x 23 W RMS acc. to DIN 45 324 at 14.4 4 x 35 W max. power Tuner Wavebands: 87,5 – 108 MHz 531 – 1602 kHz 153 – 279 kHz FM sensitivity: 0.9 µV at 26 dB signal/noise ratio.

  • Page 62: Glossary

    Glossary Access code Barred functions can be operated after the access code has been entered. Adapter card Holder for small SIM cards. With the help of an adapter card, it is possible to use small SIM cards in equipment which was otherwise designed for use with standard-sized SIM cards.
  • Page 63 You can find this code in the car radio pass. KeyCard Theft protection system from Blaupunkt. The equipment cannot be operated without the corresponding KeyCard. SIM cards (telephone cards) or a second KeyCard can only be trained using the orig- inal KeyCard.
  • Page 64 Glossary SIM card - Subscriber Identification Mod- For radio and telephone operation. The SIM card used here is in credit-card format. It is also possible to use the small SIM card (plug-in card) with an adapter card. The SIM card contains all of the data re- quired to identify the subscriber, to allocate the telephone number and the personal phone book.
  • Page 65 Index A practical example of call forwarding 124 Access 113 Add an entry 113 Adjust the volume for traffic announcements and the beep tone 88 Alter the volume 80 Alternative frequency 85 Angle 93 Answer a call 106 Anti-theft protection 78 AOC parameters 116 Audible call timer 116 Audio mode 84...
  • Page 66 Index Glossary 128 GSM emergency calls 98, 99 GSM network service area 104 GSM radio telephone standard 73 Hands-free volume 114 Handset 75, 109 Handset volume 114 Hold function 107 Ignition timer 79, 93 Important: external alarm 118 Installation 74 International calls 108 International roaming 108 Invalid KeyCard 76...
  • Page 67 Index Selecting a CD 89 Selecting a track 89 Sending SMS messages 120 Sensitivity 95 Service no. 121 Service number of your network operator 119 Show my phone number 114 SIM card memory bank 105 SMS messages 119 SMS tone 115 Specifications 127 Speed-dial 105 Static electricity 75...
  • Page 68 Blaupunkt-Werke GmbH Bosch Gruppe 0188 3/98 PfTs K7/VKD 8 622 401 054 (D/GB)
