- Page 1 Operating instructions Kiel RD 104...
-
Page 3: Table Of Contents
Contents Short description ... 17 Important information ... 20 What you need to know! ... 20 Traffic safety ... 20 Installation/connection ... 20 Anti-theft coding ... 20 Wrong code number entered ... 20 Switching the code system on ... 21 Restart following interruption of power supply ... -
Page 4: Short Description
Short description 1 ON Switching on: Press ON, the set plays with the pre- adjusted volume. You may also change this setting (see chapter “DSC pro- gramming - VOL FIX”). When “CODE” lights up in the display, read chapter “Anti-theft coding” first. Switching off: Press ON for approximately 1 second. - Page 5 network, e.g. from NDR1 to NDR4 (North German broadcaster) or to display the entire AF memory. 7 Display Radio operation Station name (NDR1 NDS) Memory bank (FM I) CD operation In the DSC mode you can choose between the CD PLAY or play- back time indication.
- Page 6 @ 1, 2, 3, 4, 5, 6 - preset buttons You can store 6 stations on each FM memory bank (I, II, and “T”). To store a station: Press button during radio operation and hold down until the radio resumes play. To recall a station: Select the desired memory bank by pressing FM.
-
Page 7: Important Information
Do not connect the loudspeaker outputs to ground! Only use the accessory and replacement parts approved by Blaupunkt. Anti-theft coding The car radio comes standard with the code system deactivated. If the anti-theft coding system is on while the power supply to the unit is interrupted (e.g. -
Page 8: Switching The Code System On
Turn the set on. “CODE” will appear in the display. • Enter the code number given in the Blaupunkt car radio passport and con- firm: See example “Restart following interruption …”. The code system is now deactivated. Optical indication of theft protec-... -
Page 9: Radio Operation With Rds
Radio operation with RDS (Radio Data System) To make radio reception even more conven- ient, an ever increasing number of FM radio stations broadcast additional information in parallel with their normal program via the Radio Data System. As soon as a radio program can be identified, the station name and possibly also a regional identifier will appear in the display, e.g. -
Page 10: Selecting A Station
Selecting a station This set allows you to receive FM stations between 87.5 and 108 MHz. Automatic seek tuning • Press / . The radio will automatically tune into the following station. If you keep the upper or lower part of the rocker switch depressed, seek tuning speeds up in upwards or downwards direc-... -
Page 11: Storing The Strongest Stations Automatically With Travelstore
Storing the strongest stations automatically with Travelstore You can use the Travelstore memory bank to automatically store the six strongest FM sta- tions sorted on the preset buttons according to their signal strength. This feature is espe- cially useful when travelling, because it will always give you the most powerful stations at a fingertip as you pass through the various reception areas. -
Page 12: Reception Of Traffic Announcements With Rds-Eon
Reception of traffic announcements with RDS-EON Many FM broadcasters provide their service area with traffic messages at regular inter- vals. All traffic program stations transmit a special telegram signal in addition to the radio pro- gram, which is recognised and decoded by the car radio. -
Page 13: Cd Operation
CD operation Inserting the disc • Switch on the set. • Insert the CD (label side facing up) wi- thout applying force. The disc is automatically pulled into the set to reach the playing position. CD reproduction starts. Ejecting the disc •... -
Page 14: Dsc Programming
DSC programming This car radio offers direct software control (DSC) to adapt a number of default settings to your personal needs and to store them. In the following you will find an overview of all the default settings adjusted at the factory. To change a programmed parameter, •... -
Page 15: Survey Of Dsc Default Settings
TA LEVEL Use this function to adjust the volume of traffic announ- cements between 1 and 9. The announcement will be played with the specified volume. VOL FIX Use this function to adjust the initial volume when the set is switched on. To quit the DSC mode and store the setting: •... - Page 16 Blaupunkt-Werke GmbH Bosch Gruppe 7/94 K7/VKD 3 D94 162 004...
