- Page 1 LANDING XNEL363672- FOOTER BAR ASSEMBLY FOR CASTERS Installation Guide 10/3/18 – REV A...
- Page 2 INSTALLATION GUIDE 1) Parts and Fasteners Included Landing End Panel Foot Bar Weldment Bracket Screw 1 5/16-18 Serrated Flanged Nut .25 x 2” Hex Head Lag Caster...
-
Page 3: Tools And Supplies Required
INSTALLATION GUIDE 2) Tools and Supplies Required Drill #2 Phillips Bit Adjustable Wrench Ratchet Socket Socket Extension... -
Page 4: Assembly Overview
INSTALLATION GUIDE 3) Assembly Overview 1. Lay the end panel of the table down to gain access to the pockets at the bottom of the panel. (Figure 2. Nest bracket in the pocket on the bottom of end panel. (Figure 2) Figure 1 3. - Page 5 INSTALLATION GUIDE 3) Assembly Overview Once both end panels have two brackets lagged and screwed in and caster attached. Assembly table as standard landing. (Figure 4) Casters not shown. Note: “L” brackets are added for strength. There are pre-drilled hole to Figure 4 locate brackets Slide footer bar between end...
- Page 6 12900 Christopher Drive Lowell, MI 49331 800.815.7251 www.enwork.com Specifications subject to change without notice.
