- Page 1 Ensto One Home EVH161-HC000 EVH321-HC000 EVH161-HCR00 EVH321-HCR00 Installation Guide User Guide RAK131_ENG 15.4.2020 © Ensto 2020...
-
Page 2: Table Of Contents
3.2. Cable entries................3.3. Wall mounting................4. Power supply.................... 5. Commissioning..................11 5.1. Installer menu in the Ensto Charger Control Application..11 6. Technical information................12 7. Dimension drawing................. 13 8. Installation / Commissioning checklist..........14 9. EVH161-HC000 / EVH321-HC000 internal circuit example....15 10. -
Page 3: Installation Guide
2. Delivery contents • EVH Charger • Cable gland M32/M25 (depending on the model) • Installation and User Guide in English, other languages please see www.ensto.com. • Multilingual Quick Guide Plug holder Plug 4-color LED indicates the charger’s status Fixed cable... -
Page 4: Mounting Instructions
In order to ensure the optimal charging performance, the charger should not be exposed to direct sunlight. • The minimum space needed for operating and maintenance. min. 200 mm min. 200 mm Recommendation 900 - 1200 mm Follow always national regulations and site requirements RAK131_ENG / © Ensto 2020 4 / 28... -
Page 5: Cable Entries
2pcs. Base Remove the screws 4pcs. Remove the installation box cover. Installation box cover TX20 Screw fixing: Remove the screws 2pcs. Mechanical lock: Unlock the hatch with a coin or suchlike. RAK131_ENG / © Ensto 2020 5 / 28... - Page 6 Black reduction nipple, M32 => M25 included 1pc RGM16B Membrane gasket for cable Ø 5 - 9mm RMM25B Membrane gasket for cable Ø 8 - 17mm RMM32B Membrane gasket for cable Ø 12 - 24mm RAK131_ENG / © Ensto 2020 6 / 28...
-
Page 7: Wall Mounting
Installation steps Use screw type depending on the wall type. Fasten the upper screw 1270 mm measured from the ground surface. The plug holder will be at a height of 1200 mm. RAK131_ENG / © Ensto 2020 7 / 28... - Page 8 Strip the leads 11 mm and connect to the supply connectors. 10. Put the installation box cover back in right position and secure with the screws you re- moved. 11. Close the installation box hatch. RAK131_ENG / © Ensto 2020 8 / 28...
-
Page 9: Power Supply
32A depending on charger model) to the supply line. In addition follow local regu- lations for the power supply line. L1 N Supply Fixed charging cable Cu 2.5 - 10 mm² RAK131_ENG / © Ensto 2020 9 / 28... - Page 10 A label set of RCBO testing instructions is included in the delivery. Attach a language spe- cific label on the installation box hatch. Supply Fixed charging cable Cu 2.5 - 10 mm² RAK131_ENG / © Ensto 2020 10 / 28...
-
Page 11: Commissioning
Ensto Charger Control Application. You can download the application from Google Play or App Store. Please see instructions in chapter 22. Ensto Charger Control Application on pages 22 - 27. 5.1. Installer menu in the Ensto Charger Control Application... -
Page 12: Technical Information
Control and EVH161-HC000 EVH321-HC000 EVH161-HCR00 EVH321-HCR00 Communication Operation mode Standalone Wireless Bluetooth (the charger can be paired with only one mobile at a time ) RAK131_ENG / © Ensto 2020 12 / 28... -
Page 13: Dimension Drawing
7. Dimension drawing RAK131_ENG / © Ensto 2020 13 / 28... -
Page 14: Installation / Commissioning Checklist
All the LED states / color (green, blue, red) are functioning. check • Use a car simulator. • Create fail and charge. • Red at bootup, green at idle and blue while charging. Ready for The latest software is in use. RAK131_ENG / © Ensto 2020 14 / 28... -
Page 15: Evh161-Hc000 / Evh321-Hc000 Internal Circuit Example
J1 J16 LED Board A1 EVI200 Supply Cu 2.5–10 mm² Note! All signal wires must be at a sufficient distance from the power wires or protected with insulating shield / plastic spiral. RAK131_ENG / © Ensto 2020 15 / 28... -
Page 16: Evh161-Hcr00 / Evh321-Hcr00 Internal Circuit Example
J1 J16 LED Board A1 EVI200 Supply Cu 2.5–10 mm² Note! All signal wires must be at a sufficient distance from the power wires or protected with insulating shield / plastic spiral. RAK131_ENG / © Ensto 2020 16 / 28... -
Page 17: Troubleshooting
Charging station is off, no lights on Issue Corrective action Mains voltage does not exist in supply Ensure proper power supply. connector L. The circuit breaker QF1 is off Turn the QF1 on. (EVH161-HCR00 and EVH321-HCR00). RAK131_ENG / © Ensto 2020 17 / 28... -
Page 18: User Guide
User Guide 12. Introduction This Installation and User Guide is for the Ensto One Home Charger family. Even if the fea- tures and appearance of the different charger versions varies, the installation and usage of the product always follow the principles described in this guide. -
Page 19: User Interfaces
15. User interfaces The charger has two operating modes “Free charging“ and “Authorized“. The default operating mode is “Free charging“. You can change the operating mode with the Ensto Charger Control application. You can download the application from Google Play or App Store. Please see instructions in chapter 22. -
Page 20: Maintenance / Preventive Maintenance Instructions
Open the installation box hatch. • Press the TEST button. • The rocker turns to 0 position. Turn the rocker back to I position. • • If a fault occurs, contact an electrician. RAK131_ENG / © Ensto 2020 20 / 28... -
Page 21: Disposal
Warranty conditions, see the product card on www.ensto.com. 21. Declaration of Conformity Hereby, Ensto Chago Oy declares that the Ensto One Home chargers are in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the follow- ing internet address: www.ensto.com. -
Page 22: Ensto Charger Control Application
22. Ensto Charger Control Application • With the Ensto Charger Control Application you can control your charger and change the settings of your charger. • Bluetooth technology is used for the wireless connection. • You can pair your mobile to several chargers, but you can be connected only to one charg- er at a time. -
Page 23: Pairing The Charger With Your Mobile Device
When the pairing is completed, you can find your charger in “My Devices”. If you want to control the charger with another mobile device, follow the pairing steps above, Note! The charger can be paired only to one mobile device at a time. RAK131_ENG / © Ensto 2020 23 / 28... -
Page 24: Application User Interface
You can charge your vehicle at a lower current than the set maximum value. Notice that in that case it takes longer to charge your vehicle fully. You can set the charging current from “Home Screen” or “Settings / Max charging cur- • rent”. RAK131_ENG / © Ensto 2020 24 / 28... -
Page 25: Charging In "Authorized" Mode
• Connect the plug to your vehicle’s receptacle. • Open the Ensto Charger Control application on your mobile device. • Press “Start” on the application. Stop charging •... -
Page 26: Error Messages
The charger has detected a software er- Contact service. ror. Switch off the charger from the main The charger has an internal malfunction. switch and then switch it on again. If the error occurs again, contact service. RAK131_ENG / © Ensto 2020 26 / 28... - Page 27 If you need to contact Ensto related to faulty operation of the charger, go first to “Support / Er- ror log”. Save the error log information before contacting. This information helps the technical support and maintenance to resolve the issue.
- Page 28 Ensto Chago Oy Ensio Miettisen katu 2, P.O. Box 77 FIN-06101 Porvoo, Finland Tel. +358 20 47 621 Customer service +358 200 29 007 ensto@ensto.com...
