Kongsberg Simrad AP20 Manual

Kongsberg Simrad AP20 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
M
A
N
U
A
L
Simrad AP20
Autopilot
A L W A Y S
A T
T H E
F O R E F R O N T
O F
T E C H N O L O G Y

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Simrad AP20 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kongsberg Simrad AP20

Summary of Contents for Kongsberg Simrad AP20

  • Page 1 Simrad AP20 Autopilot A L W A Y S T H E F O R E F R O N T T E C H N O L O G Y...
  • Page 2 This page is intentionally left blank...
  • Page 3 AP20 autopilot. Great care has been paid to simplify operation and set-up of the Simrad AP20, however, an autopilot is a complex electronic system. It is affected by sea conditions, speed of the vessel, hull shape and size.
  • Page 4 Simrad AP20 Autopilot Document revisions Written by Checked by Approved by Date Sign Date Sign Date Sign N.G. G.K. Th.H. – 22.03.97 22.03.97 22.03.97 N.G. Th.H. 07.10.97 07.10.97 N.G. Th.H. 22.06.98 22.06.98 N.G. Th.H. 20.12.99 20.12.99 N.G. Th.H. 27.03.00 27.03.00 N.G.

  • Page 5: Table Of Contents

    Instruction manual Contents INTRODUCTION ..................8 1.1 General ....................8 1.2 How to use this manual................. 8 1.3 System components................9 1.4 AP20 Control Unit ................10 1.5 Junction units ..................10 1.6 RF300 Rudder Feedback unit ............. 10 1.7 Heading Sensors.................. 10 RFC35 Electronic Fluxgate Compass..........
  • Page 6 Simrad AP20 Autopilot 2.5 Non-Follow-Up steering (NFU) ............17 2.6 R3000X Remote Control ..............18 2.7 S35 Steering lever ................18 2.8 Automatic Steering ................18 2.9 Automatic Speed selection..............19 2.10 Manual speed selection ............... 20 2.11 Navigating with the AP20..............21 2.12 Selecting a different Navigator ............
  • Page 7 Instruction manual 3.11 S35 NFU Steering Lever..............47 3.12 NMEA messages................. 48 3.13 IP protection..................50 Installation....................51 4.1 General ....................51 4.2 Installation checklist ................51 4.3 Unpacking and handling ..............52 4.4 Determine system configuration ............52 4.5 AP20 System Layout ................53 4.6 RF300 Rudder feedback installation...........
  • Page 8 Simrad AP20 Autopilot 4.21 NMEA Compass in ................71 4.22 Radar Clock/Data................72 4.23 IS15 Instrument installation ..............72 4.24 External Alarm..................74 4.25 NI300X NMEA Interface Unit ............74 4.26 CI300X Analogue Interface Unit............76 4.27 LF3000 Linear Feedback ..............77 4.28 CD100A Course Detector ..............
  • Page 9 Instruction manual Maintenance ..................... 106 5.1 Control unit ..................106 5.2 Junction Unit ..................106 5.3 Rudder Feedback................106 5.4 Compass .................... 106 5.5 Drive unit ..................106 5.6 Exchange of software programme ............ 107 Trouble shooting ..................109 6.1 Alarms ....................109 6.2 System Data Menu ................

  • Page 10: Introduction

    Simrad AP20 Autopilot INTRODUCTION General Congratulations on the purchase of your new Simrad AP20 autopilot system and thank you for selecting what we feel is the most advanced autopilot system available on the market today. Today, Simrad manufactures a complete range of autopilots for all types of vessels, from leisure boats to advanced steering systems for merchant marine vessels.

  • Page 11: System Components

    Introduction Please take time to read this manual to get a thorough understanding of the operation and system components and their relationship to a complete AP20 autopilot system. Other documentation material that is provided with your system includes a warranty card. This must be filled out by the authorized dealer that performed the installation and mailed in to activate the warranty.

  • Page 12: Ap20 Control Unit

    Simrad AP20 Autopilot AP20 Control Unit A compact autopilot control for panel, bulkhead or bracket mounting. Large LCD display for readout of autopilot data and rotary course knob. It has two Robnet connectors for system interconnection and expansion. Junction units The junction unit is the heart in the AP20 autopilot system.

  • Page 13: Rfc35 Electronic Fluxgate Compass

    Introduction RFC35 Electronic Fluxgate Compass A compact heading sensor from Simrad with 15 m (45 feet) of cable. The direction of the earth's magnetic field is sensed by a floating ring core in a fluxgate coil and transformed to a digital signal read by the autopilot steering computer.

  • Page 14: Optional Equipment

    Simrad AP20 Autopilot Optional equipment A series of options are available for the basic AP20 system. R3000X Remote Control A small handheld remote control with two push buttons for power steering or course selection (port and starboard), and one push button with built-in lighted indicator for limited mode change.

  • Page 15: Operation Of The Autopilot

    Operation OPERATION OF THE AUTOPILOT WARNING ! An autopilot is a very useful navigational aid, but DOES NOT under any circumstance replace a human navigator. Do not use automatic steering when: • In heavy traffic areas or in narrow waters •...

  • Page 16: On/Off - Standby Mode

    Simrad AP20 Autopilot The control unit shown above can operate as a stand alone unit in an autopilot system or combined in a multistation system. In a multistation system the command can easily be transferred from one unit to another. Units not in control will display "Inactive".

  • Page 17: Flashing Course Knob Icon

    Operation After approx. 5 seconds the system is operative and the unit that was turned on will show the STBY mode display. Other units in a multistation system will display "Inactive". Control can be available at any unit by pressing the STBY button. A long press (2-3 sec.) on the STBY button switches the system OFF.

  • Page 18: Operation

    Simrad AP20 Autopilot If you prefer to use the rudder angle display when leaving the dock, proceed as follows: After turn on the rudder angle display will alternate between 10 degrees port and starboard to indicate that the "rudder" zero point need be set.

  • Page 19: Non-Follow-Up Steering (Nfu)

    Operation angle is shown on the display and the rudder will move to the commanded angle and stop. HEADING Press both buttons simultaneously to Use course knob to activate Follow-Up command rudder angle RUDDER WARNING: While in Follow-Up mode, you cannot take manual control of the wheel.

  • Page 20: R3000X Remote Control

    Simrad AP20 Autopilot R3000X Remote Control In STBY mode the rudder will move as long as the Port or REMOTE Stbd button is pressed. Push buttons for Port and In AUTO mode, the set course Stbd NFU commands will change 1° each press.

  • Page 21: Automatic Speed Selection

    Operation The AP20 will keep the boat on the set course until a new mode is selected or a new course is set with either the course knob or the PORT or STBD buttons. One revolution of the course knob equals 44°...

  • Page 22: Manual Speed Selection

    Simrad AP20 Autopilot Example of Transition speeds with AUTOMATIC Speed parameter selection Transition to HI parameters with increasing speed: 10 Knots Transition Speed set to 9 Knots Transition to LO parameters with decreasing speed: 8 Knots 2.10 Manual speed selection Select AUTO mode.

  • Page 23: Navigating With The Ap20

    Operation 2.11 Navigating with the AP20 The AP20 has the capability to use steering information from an external navigator (GPS, Chart Plotter) to direct the boat to a specific waypoint location, or through a route of waypoints. In the NAV mode, the AP20 uses the heading sensor as it's reference for course keeping.
  • Page 24 Simrad AP20 Autopilot Press again to N A V activate NAV mode S E T U P Display readout: Course to steer: 348 NEXT WP HEADING Cross track error: .02 nm to stbd. EGERSUND Compass heading: 347 M or T...

  • Page 25: Selecting A Different Navigator

    Operation 2.12 Selecting a different Navigator If you have more than one navigation source connected to the AP20, you will be able to choose any for navigation. Refer to the User Set-up menu for details on selecting a different navigator. If the AP20 is connected to a navigation receiver that does not Note ! transmit a message with bearing to next waypoint, it will pick a...

  • Page 26: Dodging

    Simrad AP20 Autopilot 2.13 Dodging Dodging is useful in situations where you need to quickly take control of the helm to steer around an obstruction, and then wish to return to the previous set heading after performing the evasive manoeuvre. Dodging is activated by a quick press on the DODGE button.

  • Page 27: Dodge In Nav

    Operation 2.14 Dodge in NAV D O D G E DODGE Press to activate Dodge mode: T U R N N 0.1nm Perform dodge using: Wheel HEADING NEXT WP Non Follow Up Fishing Follow Up both To return from Dodge mode press one of the following buttons: Selects NAV mode at present position with A U T O N AV...

  • Page 28: Tacking In Auto Mode

    Simrad AP20 Autopilot 2.16 Tacking in Auto mode When the AP20 is installed on a sailboat, a fixed tack of 100 degrees can be made in AUTO mode. The use of this function should be carefully considered based on the boat's characteristics and the weather conditions. The tack...

  • Page 29: Wind Vane Steering

    Operation 2.17 Wind vane steering Prior to entering WIND mode the AP20 system should be operating in AUTO, with valid input from the selected wind transducer. The WIND mode is an alternative function to the NAV mode and it is only available if the system has been set up for SAIL-boat in the Installation Menu, and NAV/WIND source is set to WIND under the USER SETUP menu.

  • Page 30: Tacking In Wind Mode

    Simrad AP20 Autopilot 2.18 Tacking in Wind mode In WIND mode on sailboats there is also a tacking aid function. This function may only be used when the boat is reaching and will when activated take the boat from the course you are steering to the computed course that gives you the same apparent wind on the other side.

  • Page 31: Lock Function

    Operation 2.20 Lock function The "LOCK" function is a safety feature included in the AP20 system when you have more than one control unit installed. It will disable all control units except for a single, user selected control unit location. When the "lock"...
  • Page 32 Simrad AP20 Autopilot After having "unlocked" the other control stations, the "active" control unit will show the above symbol before the display returns to normal. All other control units will return to the "inactive" state. 20220505H...

  • Page 33: User Set-Up Menu

    Operation 2.21 User Set-up Menu Sequences FWD in MENU BACK SETUP Sequences BACK in Scrolls through menu Quick double press MENU selections or sets to enter value on menu items User Setup Menu SETUP Nav/Wind Backlight Contrast Nav Source ------- Seastate Filter MAN 1 SETUP...
  • Page 34 Simrad AP20 Autopilot Adjustment is local. All steps are not available at high temperatures due to automatic temperature compensation. SETUP Nav/Wind Backlight Contrast Nav Source GPS1 Seastate Filter MAN 1 Select the source for NAV mode steering. Refer to interface setup table on page 94.
  • Page 35 Operation SETUP Pos Source GPS1 Select Compass Course adjust 1° System data NMEA data Select the compass to be used for AUTO steering, if more than one compass is connected. Refer to the interface setup table on page 93. RFC = Simrad RFC35 Fluxgate compass or Simrad RFC35R Rate compass (See Note) MAGN = Magnetic compass (or Simrad RFC35 Fluxgate...

  • Page 36: Instrument Screens And Menu

    Simrad AP20 Autopilot System data and NMEA data are test functions to analyse data processed by the AP20. (See Trouble shooting page 109). Except when NMEA data or System data is displayed, the menu will disappear after 30 seconds if no key is pressed. It will disappear immediately if any mode key (STBY, AUTO or NAV/WIND) is pressed.
  • Page 37 Operation DGPS1 POSITION TRUE WIND COG 274 M SOG 2.4 kt BRG 272 M N 58 27.11' Egersund X 0.02nm D 32.2nm E 005 DGPS1 POSITION 27.20' TOTAL 3456 DISTANCE 58.32' TRIP 12.0 DISTANCE COG 125 M TRIP SOG 5.00kt 1.14 TIME GPS1 NAV DATA...

  • Page 38: Instrument Set-Up

    Simrad AP20 Autopilot Instrument set-up This screen gives access to the set-up of the Shallow Water Alarm and the Trip reset. Press and hold the INSTRUMENT button to activate the screen as shown. INSTRUMENT SETUP SET SHALLOW --.--ft RESET TRIP --.--nm...

  • Page 39: Technical Specifications

    Technical Specifications TECHNICAL SPECIFICATIONS AP20 Autopilot System Boat size and type:..... Up to 80 feet, Power, Displacement, Sail Steering system types: ....Hydraulic, Mechanical Inter-unit connection: ....ROBNET network or two-wire supply/data System ON/OFF: ....... From control units Supply voltage:......See junction units Power consumption: ....

  • Page 40: Ap20 Control Unit

    Simrad AP20 Autopilot Heading sensors: Standard: ......RFC35 Electronic Fluxgate compass Options:......Magnetic compass RFC35R Rate compass NMEA Compass (Not J3000X) Simrad RGC50/RGC10 gyrocompasses * Analogue fluxgate compass (sin/cos)* Analogue wind vane (sin/cos)* * By CI300X Course Selection:....... Rotary course dial and push button Alarms: ........
  • Page 41 Technical Specifications Display: Type: ......... Backlit LCD matrix display Resolution: ......160 x 128 pixels Colour: ........Black Illumination: ......Adjustable in 10 steps Environmental Protection:..IP56 from front, IP43 from back. Safe distance to compass: ..0.5 m (1.6 ft.) Temperature: Operating: ......

  • Page 42: Junction Units

    Simrad AP20 Autopilot Junction units Dimensions: ....... See Figure 3-2 and Figure 3-3 Weight: J300X/J3000X ....1,3 kg (2,9 lbs.) J300X-40......2,8 kg (6,2 lbs) Supply voltage: J3000X ......10-28V DC J300X/J300X-40 ....10-40V DC Reverse voltage protection ..Yes (not J300X-40) Power consumption: ....
  • Page 43 Technical Specifications Figure 3-2 J300X/J3000X Junction Unit - Dimensions Figure 3-3 J300X-40 Junction Unit - Dimensions 20220505H...

  • Page 44: Rfc35 Fluxgate Compass

    Simrad AP20 Autopilot RFC35 Fluxgate compass Dimensions: ....... See Figure 3-4 Weight: ........0,9 kg (2,0 lbs) Supply and output:..... Polarity independent 2-wire supply with superimposed pulse width modulation Automatic Performance: Calibration: ....... Automatically activated by control head Gain compensation: ..Automatically adjusted continuously Repeatability:......

  • Page 45: Rfc35R Rate Compass

    Technical Specifications RFC35R Rate compass Dimensions: ....... See Figure 3-4 Weight: ........0,9 kg (2,0 lbs) Supply and interface:....Robnet Power consumption: ....0,9 watts Automatic Performance: Calibration: ....... Automatically activated by control head ..Gain compensation: ..Automatically adjusted continuously Rate sensor stabilized heading output Accuracy:........

  • Page 46: Rf300 Rudder Feedback

    Simrad AP20 Autopilot Dimensions: ....... 160 mm x 126 mm (6.3 in x 5 in.) Weight: ........0,9 kg including cable (2,0 lbs.) Power consumption: ....0,9 watts Temperature range: Operation: ......0 to +55 °C (+32 to + 130 °F) Storage: ......

  • Page 47: Ci300X Compass Interface

    Technical Specifications Temperature range: Operation: ......–10 to +55 °C (+14 to +130 °F) Storage: ......–30 to +80 °C (–22 to + 176 °F) Transmission link: ..... Stainless 350mm (13.8") with 2 ball joints. Ball joint stud for rudder arm requires 4.2mm dia hole and 5mm tap.

  • Page 48: Ni300X Nmea Interface

    Simrad AP20 Autopilot Gyro compass input:....Synchro 1:1 (RGC10/RGC50 gyrocompasses) Heading or windvane input: ..Sin/cos max 12V DC NFU steering lever input: ..Port/stbd potential free contact Robnet network interface: ..2 network connectors Cable inlets: ....... Rubber glands for cable diam. 10-14 mm Mounting: ........

  • Page 49: R3000X Remote Control

    Technical Specifications Material:........Epoxy coated aluminium Environmental Protection:..IP44 Temperature range: Operation: ......0 to +55 °C (+32 to +130 °F) Storage: ......–30 to +80 °C (–22 to +176 °F) 3.10 R3000X Remote Control Dimensions: ..... See Figure 3-9 Weight:.....

  • Page 50: Nmea Messages

    Simrad AP20 Autopilot 3.12 NMEA messages NMEA messages and data overview for IS15, AP11, AP20, AP35, AP300X, AP3000(X) and J3xx V1R8 Message ident. Data source: p p p p p n n n (n/p/h=nav/pos/heading source, c=calculated) Accept. cond P P P P P N N N .
  • Page 51 Technical Specifications Remarks: Indata use Bold red = {IS15, J3xx and IS11Multi} M=Multi only, black = {J3xx and IS15}. Blue 'X' IS15 only. Shadowed not to be used any more N/P=nav/pos data warning, *DGPS if flag=2 d,c d,c* d,c *Not for AP35 * Output only HDG message in to IS15 see note2 d,c*...

  • Page 52: Ip Protection

    Simrad AP20 Autopilot 3.13 IP protection Each part of a Simrad autopilot system has a two digits IP protection code. The IP rating is a method to classify the degree of protection against solid objects, water ingress and impact afforded by electrical equipment and enclosures.

  • Page 53: Installation

    Installation INSTALLATION General This section provides detailed information required to successfully installing AP20 Autopilot system. The AP20 system includes several modules that need to be mounted in different locations on the boat, and also need to interface with at least three different systems on the boat: •...

  • Page 54: Unpacking And Handling

    Simrad AP20 Autopilot e) Test NAV mode and input interfaces (if connected) including optional heading sensors f) Test interface outputs to external equipment (if connected) 9. Seatrial settings (Page 96) a) Set rudder zero b) Compass calibration c) Compass Offset adjustment...

  • Page 55: Ap20 System Layout

    Installation Pay particular attention to the junction unit/drive unit combinations on page 58 and the chart on page 10. As many of the units are communicating on a common network (ROBNET), with identical connectors, the installation is simplified. Try to mount the units within the standard cable length supplied with each unit, if possible.
  • Page 56 Simrad AP20 Autopilot Do not try to remove the transmitter arm from the feedback unit. Note ! The unit is factory adjusted and need no further adjustment at installation than described below. As a starting point, it is desirable to set the transmitter rod to the inner limit of the outer slot if possible.

  • Page 57: Junction Unit Installation

    Installation Due to space limitations, it may be necessary to cut the length of Note ! the transmitter rod to move the RF300 closer to the rudder post. Tighten the mounting screws for both the RF300 feedback unit and the transmitter rod ball joint. Observe the RF300 while someone turns the helm wheel through the complete travel from full port to full stbd.

  • Page 58: Cable Connections

    Simrad AP20 Autopilot Cable connections Use only shielded cables. This includes Mains input, drive units and if necessary for the extension of the RF300 Rudder Feedback cable. The clutch/bypass cable and the solenoid cable should be 1,5 mm (AWG14). Signal cables should be 0.5 mm (AWG20) twisted pairs.
  • Page 59 Installation Pull out each terminal before connecting the wires. Remove all Note! strands before putting on the terminal cover. Ground terminal The Mains input is not polarity protected on J300X-40. TB9 and TB10 are not on the J3000X Power Board Power Board terminals Main Board terminals 20220505H...

  • Page 60: Drive Unit Installation

    Simrad AP20 Autopilot 4.10 Drive unit installation The relation between drive units, drive unit voltage, input voltage, drive output and interfacing to steering gear are shown in the table below. The AP20 system detects whether a reversible motor or a solenoid is connected and outputs the correct drive signal automatically.
  • Page 61 Installation LINEAR DRIVE UNITS MODEL MOTOR JUNC- PEAK HARD- PWR. TILLER VOLTS TION STROKE THRUST RUDDER OVER CON- UNIT mm (in.) kg (lb.) TORQUE TIME SUMP. sec. (in.) (lb.in.) (30% load) MLD200 J3000X 300 (11,8) 1,5-6 A (440) (4350) (10,4) HLD350 J3000X 200 (7,9)

  • Page 62: Connecting A Reversible Pump

    Simrad AP20 Autopilot PREVIOUS MODELS DRIVE UNITS Model Motor Junction Drive output Interface to voltage unit steering gear RPU100, J300X Proportional Hydraulic RPU150, rate plumbing (Reversible hydraulic pump) MRD100 J300X 12V to clutch Chain/ (Reversible 24V to clutch sprockets mechanical...

  • Page 63: Connecting A Hydraulic Linear Drive

    Installation Connecting a hydraulic linear drive HYDRAULIC JUNCTION UNIT LINEAR DRIVE POWER PCB TB1 TB2 TB3 TB4 TB5 Bypass Clutch Single pole clutch/bypass switch Figure 4-6 Connecting a hydraulic linear drive Connecting a solenoid valve JUNCTION UNIT SOLENOID VALVE POWER PCB TB1 TB2 TB3 TB4 TB5 Sol.

  • Page 64: Control Unit Installation

    Simrad AP20 Autopilot 4.11 Control unit installation Avoid mounting the control unit(s) where it is easily exposed to sunlight, as this will shorten the lifetime of the display. If this is not possible, make sure the units are always covered with the white protection cover when not used.

  • Page 65: Optional Bracket Mounting

    Installation Optional bracket mounting • Locate the cradle on the mounting site and mark the 4 holes for the fixing screws on the mounting surface. • Drill the 4 mounting holes and screw the cradle to the mounting surface. • Use the supplied screws to fasten the control unit to the left and right brackets.
  • Page 66 Simrad AP20 Autopilot When installing a system, try to minimize total Robnet cable length by connecting all Robnet units to the nearest available Robnet connector. Total length of Robnet cable installed in a system should not exceed 50 m (165').

  • Page 67: Ap21 Connection

    Installation AP20 JUNCTION UNIT CONTROL UNIT MAIN PCB Pnk Gry Yel ROBNET Figure 4-10 Control unit connection HOW TO REMOVE PINS: Extraction tool Pull the wire Insert tool in slot For installations that require special cable length, contact your Note ! Simrad distributor for information.

  • Page 68: Rfc35 Fluxgate Compass Installation

    Simrad AP20 Autopilot 4.13 RFC35 Fluxgate Compass installation Figure 4-11 RFC35 mounting The heading sensor is the most important part of the AP20 system and great care should be taken when deciding the mounting location. As the heading is displayed on the AP20 Control Unit, the heading sensor can be mounted at a remote location.

  • Page 69: Rfc35R Rate Compass Installation

    Installation Use the supplied mounting kit and drill the holes through the centre of the slots in the sensor or the mounting brackets. The compass face plate on the RFC35 is the TOP. Never mount Note ! it upside down! Level the sensor as close to horizontal as possible.
  • Page 70 Simrad AP20 Autopilot • Alternatively, if there is no free receptacle, cut the connector from the cable and connect the wires in parallel with the wires going from the junction unit to the control unit. Do not connect the yellow and the green wire, but secure them from connection to the terminal or chassis.

  • Page 71: R3000X Remote Control Installation

    Installation 4.15 R3000X Remote Control installation R3000X should be mounted in the supplied bracket that can be fixed by four mounting screws. The unit is weather proof and can be mounted outdoor. R3000X JUNCTION UNIT REMOTE CONTROL POWER PCB T B 1 T B 2 TB3 TB4 TB5 T B 8 G n R ed Blu...

  • Page 72: Interfacing

    Simrad AP20 Autopilot The unit is opened by removing the three screws on the back cover. Inside are two sets of micro-switches, a printed circuit board with a plug-in terminal and a jumper strap. 4.17 Interfacing With the AP20 autopilot system there are several possibilities to connect to other equipment for data exchange: 1.

  • Page 73: Double Nmea Input/Output

    Installation 4.19 Double NMEA input/output LORAN C J300X/J300X-40 JUNCTION UNIT (OR PLOTTER) MAIN PCB POWER PCB TB13 TB14 TB10 (OR PLOTTER) NMEA NMEA NMEA NMEA Output1 Input 1 Input2 Output2 Figure 4-18 Double NMEA connection 4.20 Additional NMEA output on Port 2 (Applies for AP20 V1R3/J300X V1R8 onwards) Output signal Output terminal...

  • Page 74: Radar Clock/Data

    Simrad AP20 Autopilot 4.22 Radar Clock/Data ANRITSU J300X JUNCTION UNIT P O W E R P C B FURUNO RADAR T B 8 T B 1 0 T B 9 R a d a r Figure 4-20 Radar Clock/Data connection 4.23...
  • Page 75 Installation Figure 4-21 IS15 Instruments / J3XX Connection Figure 4-22 IS15 Expander / J3XX Connection 20220505H...

  • Page 76: External Alarm

    Simrad AP20 Autopilot 4.24 External Alarm The external alarm circuit has an open collector output for an external alarm relay or buzzer. The operating voltage for the circuit is the main supply voltage. Max. load on external alarm output is 0.9 Amp.
  • Page 77 Installation no radar Clock/Data output as compared to J300X and J300X- 40). Configuration for Anritsu or Furuno is selected in the Installation Menu. 12V out can drive max. 2 IS15 instruments (max 250mA load), e.g. “Rudder” and “Compass”. 12V DC BLACK MAX 250 mA SIGN.

  • Page 78: Ci300X Analogue Interface Unit

    Simrad AP20 Autopilot 4.26 CI300X Analogue Interface Unit The CI300X analogue interface unit is an optional module, designed to enable a variety of different equipment to connect into AP20 systems. The CI300X converts the analogue inputs into Robnet compatible signals for use by AP20 system components.

  • Page 79: Lf3000 Linear Feedback

    Installation CI300X COMPASS INTERFACE MAGNETIC COMPASS WITH CD100A COURSE DETECTOR Vref FLUXGATE COMPASS WITH SINE/COSINE OUTPUT DC SUPPLY WIND VANE RGC10/RGC50 GYRO COMPASS CD100 CONNECTIONS: NON FOLLOW UP STBD ALT. 1 ALT. 2 STEERING PORT BROWN BLACK* LEVER ENAB WHITE ORANGE GREEN GREEN...
  • Page 80 Simrad AP20 Autopilot The 8,5 m (28') cable is terminated in the LFI3000 Mk2 Linear Feedback Interface according to the wiring diagram. Center the drives. Loosely secure the LF3000 to the supplied mounting bracket, across the center of the drive unit cylinder.

  • Page 81: Cd100A Course Detector

    Installation Electrical connection LFI3000 Mk2 JUNCTION UNIT LINEAR FEEDBACK MAIN PCB INTERFACE Rudder Feedb. Figure 4-27 LF3000/LFI3000 Mk2 connections The previous LFI3000 had no centre block terminal for screen Note ! termination. 4.28 CD100A Course Detector On some installations the owner may prefer to use the boats own compass.

  • Page 82: Cdi35 Interface

    Simrad AP20 Autopilot 4.29 CDI35 Interface Locate the CDI35 as close to the compass as possible so that there will be no problem finding it in the event of a service. Put the two fixing screws in the slots and secure the unit to the bulkhead.

  • Page 83: Software Setup Procedure

    Installation 4.30 Software Setup Procedure Description of Installation Settings The design of the AP20 includes advanced features that have simplified the installation and setup of an autopilot. The principle advantage is that manual adjustments that needed to be done on previous models are no longer necessary with the AP20. The installation settings must be performed as part of the Note ! installation of the AP20 system.

  • Page 84: Installation Menu

    Simrad AP20 Autopilot on and if an attempt is made to access the AUTO or NAV modes prior to completion of setup. • The Dockside, Interface and Seatrial settings can only be accessed when the system is in STBY mode.
  • Page 85 Installation ENTER INSTALLATION MENU SYMBOLS INSTALLATION BY PRESSING AND HOLDING THE MENU NAV BUTTON FOR 5 SECONDS SELECT OR CONFIRM BY ROTARY COURSE SELECTOR LANGUAGE MENU GO TO NEXT MENU ITEM BY PRESSING STBD BUTTON LANGUAGE ENGLISH DEUTSCH REVERT TO PREVIOUS FRANCAIS MENU ITEM ESPANOL...

  • Page 86: Language Selection

    Simrad AP20 Autopilot There are several actions that you can do once you have accessed the IM: • Answer YES to the question by rotating the course knob clockwise. • Change the selected item shown by rotating the course knob.

  • Page 87: Dockside Settings

    Installation 4.31 Dockside settings The following menu items are accessible and can be set up in the Dockside Menu: • Boat type • Drive Unit voltage • Rudder Feedback calibration • Automatic Rudder test • Transition Speed In addition the Dockside Menu display will show: •...

  • Page 88: Rudder Feedback Calibration

    Simrad AP20 Autopilot Refer to the drive unit table on page 58 for information. It is not possible to select a higher voltage than the input voltage. The CLUTCH/BYPASS voltage is automatically set to the same as the drive unit voltage. In Rudder Test, the AP20 system will automatically detect whether the drive unit is a reversible motor or solenoid operated.
  • Page 89 Installation The display will show with the rudder in mid position: Dockside Turn Rudder max. STBD Adjust? Manually turn the helm to starboard until the rudder stops at maximum starboard rudder. Dockside Turn Rudder max STBD Adjust? The value shown on the display is the value read by the rudder feedback unit before any adjustment is made.

  • Page 90: Automatic Rudder Test

    Simrad AP20 Autopilot Adjust the displayed angle the same way as for starboard adjustment. (This time you need not correct for wrong side if the rudder feedback unit is upside down). Rudder zero may still not be accurate but will be adjusted later Note ! during sea trial.

  • Page 91: Transition Speed

    Installation Dockside Dockside Boat type Planing Boat type Planing Drive unit voltage Drive unit voltage Rudder max STBD Rudder max STBD Rudder max PORT Rudder max PORT Rudder test Done Rudder test Done Motor Drive out xx% Solenoid drive Clutch NOT Installed Clutch NOT Installed Transition speed 00kn...

  • Page 92: Interface Settings

    Simrad AP20 Autopilot It is recommended that you set the transition speed to a speed that represents the speed where the hull begins to plane, or where you would manually change the parameters from HI to LO. The speed used for the automatic transition is obtained as follows: 1.
  • Page 93 Installation Abbreviated Equipment / Usage NOTES name GPS1 Primary GPS Can be used as either NAV source or POS source. Also for VTG GPS2 Backup GPS data for automatic AUTO HI/LO speed selection LC 1 Loran NAV1 Chart plotter NAV2 Other Nav source.
  • Page 94 Simrad AP20 Autopilot Interface setup - input signal Setup item Equipment Hardware port terminal Hardware port (abbrev. connected (use one available from list) to be assigned name) (* = default setting) GPS1 Not connected – – – – J3XX, Main PCB NMEA I/P RX1+,RX1–...
  • Page 95 Installation Setup item Equipment Hardware port terminal Hardware port (abbrev. connected (use one available from list) to be assigned name) (* = default setting) INSTR Not connected – – – – WIND J3XX, Main PCB NMEA I/P RX1+,RX1– J300X-1* J300X, Power PCB NMEA I/P RX2+,RX2– J300X-2 NI300X, NMEA port #1 NI300-1...
  • Page 96 Simrad AP20 Autopilot SETUP MENU to provide the user with choices of data sources, or identified to the AP20 where to look for various types of data. When you assign a hardware port to an abbreviated name, you are simply telling the AP20 system that when the user chooses an abbreviated name as a data source it should look to the hardware port assigned to the abbreviated name for data.
  • Page 97 Installation Assign a hardware port to the name by turning the course knob until the hardware port is displayed along with the name. Proceed to the names on the list that shall be assigned by pressing STBD [>] button. Select appropriate hardware ports by turning the course knob, or exit from menu by stepping through the list of names by pushing STBD [>] button.

  • Page 98: Sea Trial

    Simrad AP20 Autopilot 4.32 Sea Trial The Sea-trial menu can only be accessed if the Dockside Settings are done and confirmed. It is also recommended that the Interface Setup be performed prior to Seatrial settings. The seatrial settings do the following: •...

  • Page 99: Compass Calibration

    Installation • Bring the boat up to cruising speed, and head directly into the wind. • If the boat has twin engines, synchronize the engine RPM's. • Set the trim tabs and stabilizers to have no effect on the boats heading.

  • Page 100: Compass Offset

    Simrad AP20 Autopilot Seatrial Seatrial Set Rudder zero Set Rudder zero Compass Compass calibrating calibration Compass offset Compass offset Heading Heading Automatic tuning Automatic tuning 1. Begin turning the boat to starboard (can also turn to port). 2. Start compass calibration by turning the course knob clockwise.

  • Page 101: Automatic Tuning

    Installation (For multiple heading sensor offset procedure, refer to separate CI300X manual). The following display is presented when accessing the COMPASS OFFSET screen: Seatrial Set Rudder zero Compass calibration Compass offset Heading Automatic tuning Dial in the correction by turning the course knob to offset the compass heading to agree with a known heading or bearing.
  • Page 102 Simrad AP20 Autopilot Recommended speed during Autotune varies with the type of boat, but should not exceed 10 knots. Autotune should not be performed at planing speed! For displacement boats use a speed that is approximately half the normal cruising speed (i.e. if cruising speed is 10 knots, do the Autotune at about 5 knots).

  • Page 103: View Parameters

    Installation View parameters Parameter Rudder 0.50 Cont.Rudder LO 1.40 Autotrim 40 sec. Rudder Lim 20° Rudder 0.35 Cont.Rudder HI 1.00 Autotrim 40 sec. Rudder Lim 20° A boats steering parameters found by Autotune can be looked at and if needed changed under this menu item. The steering parameters can also be set manually instead of performing an Autotune.
  • Page 104 Simrad AP20 Autopilot The two most important parameters that determine the performance of the automatic steering are Rudder and Counter Rudder. Rudder sets the rudder gain which is the ratio between the commanded angle and the heading error ( P-factor).

  • Page 105: Nmea Test

    Installation New course Correct setting of counter rudder, ideal response Autotrim standard value is 40 sec. which should work well on most boats. Rudder Limit should be kept at 20 degrees unless there is a need for more rudder when performing dockside manoeuvres. Caution ! In no event should the Rudder Limit be set to a value higher than the actual maximum rudder angle.

  • Page 106: Master Reset

    Simrad AP20 Autopilot Exit the Display Units menu by pressing STBD [>] button to proceed to the Master Reset menu, or press STBY to return to normal AP20 operation. Master Reset Language Dockside Interface Seatrial Parameters NMEA Test Display Master Reset...

  • Page 107: Providing User Training

    Installation transition speed is crossed (by more than 1 Knot higher or lower speed). • Try the Dodge function and the U-turn. • If a Non-Follow Up lever (or handheld remote) is connected, test the mode switching and verify Port and Stbd steering commands of the lever.

  • Page 108: Maintenance

    Simrad AP20 Autopilot MAINTENANCE Control unit The AP20 Control Unit will under normal use require little maintenance. If the unit requires any form of cleaning, use fresh water and a mild soap solution (not a detergent). It is important to avoid using chemical cleaners and hydrocarbons such as diesel, petrol etc.

  • Page 109: Exchange Of Software Programme

    Maintenance Exchange of software programme Junction Unit PROM Figure 5-1 J3000X/J300X/J300X-40 Main PC-Board AP20 Control Unit PROM Figure 5-2 AP20 PCB, component layout 20220505H...
  • Page 110 Simrad AP20 Autopilot • Remove the PROM from the socket by means of the special extraction tool (p/n 44139806). • Insert the tool by pressing the two grip pins down into the two slots in the corners of the socket.

  • Page 111: Trouble Shooting

    Trouble shooting TROUBLE SHOOTING An autopilot is a complex system and the performance is dependent of a proper installation and a successful sea trial. In the event of a failure, you will be helped by the AP20 software which contains several test features that will assist you in isolating a probable fault.
  • Page 112 Simrad AP20 Autopilot Display Probable fault Recommended action readout Rudder test Following conditions Refer to recommended actions for the failed may exist: specific probable faults. a) Rudder feedback failure b) J3XX current overload c) Bypass/clutch overload Rudder moves in one...
  • Page 113 Trouble shooting Display Probable fault Recommended action readout Compass data No data from 1. If more that one compass is missing selected compass. connected to the system, refer to the USER SETUP menu to select a different compass. 2. Check connections/Interface menu. 3.
  • Page 114 Simrad AP20 Autopilot Display Probable fault Recommended action readout Data failure Wrong checksum Perform a "Master reset" and make a J3XX on memory new "Dockside set-up". Switch off and parameters or on again. If the alarm is repeated, replace variables. Junction Junction unit Main PCB.

  • Page 115: System Data Menu

    Trouble shooting Alarms in AUTO and NAV: The boat is off Extreme weather 1. Check steering parameters (Rudder, course conditions, too slow Autotrim, Seastate-filter). speed. 2. Increase Rudder value Boats heading is 3. Increase boat speed, if possible, or outside fixed off steer by hand.

  • Page 116: Nmea Data Menu

    Simrad AP20 Autopilot SYSTEM DATA Compass Heading 245.4°M Rudder Angle S12.50° Steer Course 240° System Filter values Fc: 00s db:00° Compass heading readout M=Magnetic, G=Gyro (True) Rudder angle. Normally between zero and 45 degrees. Steered course in Auto and Nav. mode.

  • Page 117: Nmea Signal Monitor

    Trouble shooting One of the following codes will be displayed: No data or no NMEA sentence containing the data needed available at the input port. Valid data found Message with invalid information. Message has format failure such as a) Incorrect check sum b) Wrong contents in datafield(s) NMEA DATA NMEA DATA...

  • Page 118: Nmea (Hardware) Test

    Simrad AP20 Autopilot NMEA (hardware) test Access the NMEA Test from the INSTALLATION Menu (see page 82). NMEA Test Loopback NMEA1 Loopback NMEA2 FAILED On the Main PCB in the junction unit disconnect the cables and connect TX1+ to RX1+ and TX1- to RX1-. Similar on the Power PCB connect the NMEA ports the same way;...

  • Page 119: Spare Parts List

    Spare parts list SPARE PARTS LIST AP20 Control Unit 22084594 AP20 Control Unit 22084586 Standard mounting kit consisting of: 22084693 Gasket (2 mm) 22086029 Gasket (7.5 mm) 22084529 Cabinet corner 44162840 Cover for plug 44165181 Screw 3,5x19 44165645 Screw 3,5x32 22084941 Optional mounting kit consisting of: 44148906 Screw M4x12...
  • Page 120 Simrad AP20 Autopilot 22081640 PROM for all junction units 22081434 J300X/J3000X Base plate 22082036 J300X-40 Base plate 22081350 Main cover 22081368 Terminal cover RFC35 Electronic Fluxgate Compass 22081459 RFC35 Fluxgate Compass 22081442 Installation accessories consisting of: 20104972 Mounting plate (2) 44140762 Screw 3.5x25 (2)
  • Page 121 Spare parts list CI300X Compass Interface 22081137 CI300X Compass Interface 22082044 CI300X PCB Ass'y 20193256 20193264 Cover 44138816 Cover nutknobs 20191607 Robnet Cable 7m NI300X NMEA Interface 22081129 NI300X NMEA Interface 20191607 Robnet cable 7m 22081913 NI300X PCB Ass'y 20193256 20193264 Cover 44138816...

  • Page 122: Glossary

    Simrad AP20 Autopilot GLOSSARY NMEA 0183 - A format (language) designed to permit communication between various types of marine electronic equipment. In essence this is a two-wire shielded, serial data link, permitting one device to talk while other devices listen.
  • Page 123 Glossary BRG POS - WP – Bearing to a specified waypoint from present position. SOG - Speed over ground is the actual speed of the vessel relative to the ocean floor. COG - Course Over Ground - The actual direction of progress of a vessel, between two points, with respect to the surface of the earth, The vessels heading may differ from the course over ground due to the effects of wind, tide, currents.
  • Page 124 Simrad AP20 Autopilot Index alarm installation, 66 external, 74 specifications, 42 listing, 109 follow-up steering, 16 automatic tuning, 99 grounding, 56 autotrim, 101 illumination. See backlight backlight, 31 installation menu, 82 cable INSTR button, 34 Robnet, 63 instrument specifications, 56...
  • Page 125 Index view, 101 software setup, 81 position source, 32 specifications, 37 radar connection, 72 speed selection rate compass automatic, 19 installation, 67 manual, 20 remote control steering lever installation, 69 installation, 69 specifications, 47 specifications, 47 rudder system setting, 102 basic, 9 rudder feedback components, 9...

  • Page 126: Terms Of Warranty

    Simrad AP20 Autopilot TERMS OF WARRANTY, SIMRAD AS PRODUCTS SIMRAD warrants that every product shall be free of defects in material and workmanship as specified below: CATEGORY “A”: • Autopilots • Radars • Instruments • Navigators • Radiotelephones • Plotters •...
