SX VIDEO SERVER FORMATS
Codec and format support is subject to change. Please check to make sure you have the latest version of this document: trms.com/support/documentation
SD SERVERS - SXLE, SX2, SX4
Supported File
Codecs Extension
MPEG2 .mpg .mpeg Main (420), 422
DVCAM .avi .mov .mp4
DVCPRO .avi .mov .mp4
DV50 .avi .mov .mp4
H.264 .mov .mp4 Main, High, High 10, High 422
XDCAM SD .mov
IMX .avi .mov
SX2HD-OUTPUT 480i / 1080i
Supported File
Profile
Codecs Extension
MPEG2 .mpg .mpeg Main (420), 422
DVCAM .avi .mov .mp4
DVCPRO .avi .mov .mp4
DVCPRO HD .avi .mov .mp4
DV50 .avi .mov .mp4
H.264 .mov .mp4 Main, High, High 10, High 422
XDCAM SD .mov
XDCAM HD .mov Main (420)
.mov
XDCAM HD 422 422
XDCAM EX .mov .mp4 422
.avi .mov
IMX
Apple ProRes .mov 422, 422HQ, 422LT, 422Proxy
SX2HD-OUTPUT 720p
Supported File
Codecs Extension
MPEG2 .mpg .mpeg
DVCPROHD .avi .mov .mp4
H.264 .mov .mp4
XDCAM HD 422 .mov
XDCAM EX .mov .mp4
Apple ProRes .mov
