5.2.4 SD SX AV Connections
5.2.5 HD SX AV Connections
5 Legacy SX Servers
Each SD SX video breakout cable has the following connections:
CVBS In : Encoder composite video input
U/Y In : Not used
V/C In : Not used
AES In : Encoder AES/EBU input
SDI In : Encoder SDI input
Y/CVBS Out A : Playback channel 1 composite output
U/Y Out : Not used
V/C Out : Not used
AES Out 1/2 : Playback channel 1 AES/EBU output
SDI Out A : Playback channel 1 SDI output
CVBS Out B : Playback channel 2 composite output
AES Out 3/4 : Playback channel 2 AES/EBU output
SDI Out B : Playback channel 2 SDI output
Each SD SX audio breakout cable has the following connections:
The audio connections on the Cablecast SX servers are balanced. If your AV
infrastructure requires unbalanced audio, you will need to use proper converting
equipment to convert to unbalanced.
The SX2-HD video breakout cable has the following connections:
SDI In A : Encoder SDI video Input
SDI In B/Key : Not used
Analog Ref In : Reference signal input (tri-level or blackburst)
SDI Out A : Playback channel 1 SDI output
SDI Out B : Not used
Y In : Not used
Ref In : Genlock input
In 1 : Encoder audio input (Left)
In 2 : Encoder audio input (Right)
Out 1 : Playback channel 1 audio output (Left)
Out 2 : Playback channel 1 audio output (Right)
Out 3 : Playback channel 2 audio output (Left)
Out 4 : Playback channel 2 audio output (Right)
