3.4.2 Record Tab
F 3.10: Record tab for an
IGURE
SX-4.
3.4.3 System Tab
3 Part II: Software Setup
playback has progressed.
The status column updates approximately once every five seconds, it is not a
real-time status monitor of your video server.
The Record tab (seen in figure 3.10) allows you to configure several options for
encoding video on your video server:
ing) will be encoded if available. The VBI data stream will be automatically saved
as a separate file next to the video file, with a file name of "vbi_<filename>.avi".
Video Input : Selects which of the video inputs will be used to
record video. Choices are Composite, Component (not supported), S-Video, SDI,
and Bars.
Audio Input : Selects which of the audio inputs will be used to
record audio. Choices are Analog, Embedded
Changing the values of the record controls will apply your changes in real-time.
It may not be a good idea to alter these settings while your video server is
actively encoding.
The component video input and the AES/EBU audio input are not supported on
the Cablecast SX servers. While you may choose to use them, Tightrope Media
Systems will not be able to provide help or support for these configurations.
In the System tab (shown in figure
other settings and features of your video server. The first setting (in the Resolution
section) allows you to adjust the video resolution that the SX server uses. Choices
include 480i SD, 480i Widescreen, or 576i SD PAL, HD servers also support 720p
1280x720 and 1080i 1920x1080.
4
available only when SDI is selected as the video input
VBI : When checked, VBI data (V-chip, closed caption-
4
, AES/EBU, and Tone.
3.11 on the next page), you can configure various
