F 3.7: Setting up the record
IGURE
device.
3.4 Cablecast Video Server Settings
3.4.1 Playback Tab
3 Part II: Software Setup
The last set of software settings allow you to modify specific playback and record
parameters of the Cablecast video server. All of these settings are configured via
the SX Configuration system tray utility that is installed on the Cablecast video
server, and cannot be configured via the Cablecast Web Interface. To access the SX
Configuration utility, double-click on the icon in the system tray.
The SX Configuration utility looks like a green circle with the letters SX in the
middle (see figure 3.8 on the following page).
The Playback tab (seen in figure
options for each output:
Component output : This option is only available on output 0 (and
output 2 on the SX-4) of the SD SX servers (SX-LE, SX-2, and SX-4), and is not
officially supported by Tightrope Media Systems. When this option is enabled, the
composite cable for the output (labeled Y/CVBS Out A is transformed into the "Y"
part of the three component cables. Disabling this option returns the Y/CVBS Out
A cable to carrying composite video.
Audio level : Allows you to configure the audio level for this
3.9 on the next page) allows you to configure two
