Tightrope Media Systems Cablecast Setup Manual page 12

3.3.1 Create Playback Devices
F 3.5: Setting up the first
IGURE
playback device.
3 Part II: Software Setup
1. Click the New button to create the first playback device.
2. Click in the newly created device (labeled New Input) to enter the Edit
Device screen.
3. Enter the following information in the device fields:
Router Input : Enter the input number of your routing
switcher
Device Function : "Playback Only"
Device CMS : Select the "Video Playback" Control Mod-
ule Set that you created in section
Device Address : "0". Device addresses are zero-based, so
the first playback device's address is zero.
Device End Action : Select "None"
When finished, your screen should like like figure 3.5. Click Save to return to the
device list screen.
If your server has additional outputs, you will now create additional playback
devices.
Name : "Playback 1"
Device Type : "Digital File"
3.2 on page 9.
11
