5 Legacy SX Servers
5.1 In the box
This chapter goes over the details of legacy Cablecast SX servers.
The Cablecast SX server should come with the following items in the box:
AC power cables : Powers the Cablecast SX server.
Server : The Cablecast SX server itself.
SX breakout cables : These breakout cables allow you to connect the
SX server into your station's infrastructure. See figure
example of SD breakout cables for the SX-LE, SX-2, and SX-4. figure
following page shows an example of the HD breakout cables for the SX2-HD. The
SXLE-HD does not require any breakout cables.
The SX-LE and SX-2 come with one set of two breakout cables (one video and
one audio), and the SX-4 comes with two sets of video and audio cables (two
video, two audio). The SX2-HD also has one set of two breakout cables (one
video and one audio) but they carry SDI video and AES/EBU audio.
5.1 on the next page for an
5.2 on the
