4.3 Test Recording
4.4 Note On Passthrough
F 4.1: SX Configuration
IGURE
monitoring a passthrough.
4 Part III: Testing
Next, we'll test audio and video recording. On the Cablecast video server, perform
the following steps for your configured video input or inputs.
1. Connect valid video and audio sources to the record input.
2. Double-click the SX Configuration utility and select the Record tab.
3. Click the Record button on an input.
4. In the Save As dialog box that appears, navigate to a directory, enter a name
for your video file and click Save.
5. The Cablecast video server should begin recording to the file you selected.
6. After recording for about a minute or so, click the Stop button for the input.
7. The Cablecast video server will stop recording.
8. Repeat the playback tests (from section
newly recorded file to make sure that both audio and video were correctly
recorded.
If your file doesn't play back and you suspect it wasn't recorded correctly:
• Are you connected to the correct video server BNC connectors?
• Double check your video/audio source. Does it display correctly if
plugged in directly to a monitor?
If everything appears correct, you may need to go back and double check your
software configuration.
It is not possible to test passthrough using SX Configuration. However if a
passthrough is active the Playback tab will display that it is actively passing
through video from an encoder on the system. Stopping the output channel will
stop the active passthrough.
4.2 on the preceding page) with the
