5.4: The Cablecast SX2
IGURE
1. AC Power
2. PS2
3. USB 2.0
4. RS-232
5. Ethernet
6. USB 3.0
7. DVI-I and DisplayPort
8. AUDIO
9. VIDEO
1. Connect the video breakout cable to the VIDEO port.
2. Connect the audio breakout cable to the AUDIO port.
See section
5.2.4
for an explanation of the connectors on each breakout cable.
SX-4
1. Connect a video breakout cable to the VIDEO port labeled AV I/O 1.
2. Connect a video breakout cable to the VIDEO port labeled AV I/O 2.
3. Connect a audio breakout cable to the AUDIO port labeled AV I/O 1.
4. Connect a audio breakout cable to the AUDIO port labeled AV I/O 2.
1. AC Power
2. PS2
3. USB 2.0
5 Legacy SX Servers
23
