SB-25V Drill Press
OWNERS MANUAL
FOR YOUR OWN SAFETY AND
OPTIMUM OPERATION READ
INSTRUCTION MANUAL BEFORE
OPERATING DRILL PRESS
RETAIN THIS MANUAL FOR
FURTHER REFERENCE.
4/1/14
Fax: 616-842-0859 800-846-3253
E-mail:
Model: SB-25V
customerservice@dakecorp.com
Advertisement
Related Manuals for Dake SB-25V
Summary of Contents for Dake SB-25V
- Page 1 724 Robbins Road, Grand Haven, MI 49417 Phone: 616-842-7110 800-937-3253 Fax: 616-842-0859 800-846-3253 Web: www.dakecorp.com E-mail: customerservice@dakecorp.com SB-25V Drill Press OWNERS MANUAL FOR YOUR OWN SAFETY AND OPTIMUM OPERATION READ INSTRUCTION MANUAL BEFORE OPERATING DRILL PRESS RETAIN THIS MANUAL FOR FURTHER REFERENCE.
- Page 2 Distributed by: Trick-Tools 75 Truman Road Pella, IA 50219 Phone:1-877-VAN-SANT E-mail: sales@trick-tools.com Here at Trick Tools we believe that our customers deserve the best value in their tool and equipment purchases. We are constantly at work searching out a variety of high quality, high performance tools to offer at the best prices possible.
- Page 3 TABLE OF CONTENTS Model specifications, Uncrating and installation page 2 Safety page 3 - 4 Operation and set-up instructions page 5 , 6-11 Basic tapping instructions and tips page 6 Operatation of drill press page 7 ...
- Page 4 MODEL AND SPECIFICATIONS Machine Specifications: Model SB-25 Drill Type Floor Max. Drill Capacity 1” Spindle Taper Spindle Travel 5” Max. Work Diameter 18” Speeds (Step Pulley) Spindle Speed Range 270-2000 Column Diameter 3-5/8” Table 14 x 14” Base 23-1/2 x 15” Spindle to Table 28-1/4”...
- Page 5 moving parts. Breakage of parts or mountings and any other conditions that affect its operation. SAFETY Keep guards in place and in working order. Remove adjusting key and wrenches. Be in the habit of checking to see that keys and adjusting wrenches are removed from tool before turning it on.
- Page 6 Do not open any cover or remove any guard without proper lockout of equipment. Only a qualified electrician with proper PPE should perform electrical work on this equipment. Some components in this equipment may store electricity. BEFORE USE, ALL SAFETY POINTS MUST BE READ AND UNDERSTOOD! Operation of the drill press incorrectly, or in a dangerous fashion can result in serious injury or death.
- Page 7 Familiarize yourself with the controls before operating. Emergency stop button When this is pressed the power to the motor and controls is disconnected. The frequency drive stores energy this will remain lit for about 20 seconds. Spindle direction Turn the spindle direction switch to the desired direction forward, reverse or stop. If the emergency stop button is pushed or if the power is lost you will have to move this to stop (TO RESET) then to desired spindle direction.
- Page 8 Tapping operations using the reverse feature Drill the initial hole on the drill press for accuracy of diameter. If the diameter is 1/2 inch or larger, drill a pilot hole about half that diameter first. Make sure the hole has a large enough chamfer. If the chamfer is too small the tap will work a little hard when starting the tapping operation.
- Page 9 1. OPERATION (PROCEDURE) Drill / Chuck Installation: To show greater detail Chuck guard is in the open position in POWER MUST BE OFF BEFORE photos. CHUCK GUARD MUST IN MAKING ANY ADJUSTMENTS! PLACE DURING OPERATION! TURN POWER OFF! Before inserting drill bits, chucks or arbors, always clean out spindle hole and taper hole with a clean cloth.
- Page 10 Table tilting adjustment: Using an adjustable or box wrench loosen table level lock bolt. Carefully tilt the table to the degree needed, as shown on the angle index scale located on the table rotation point. Retighten nut securely. Note: Never tilt table if any material or fixturing is on it.
- Page 11 TURN POWER OFF! Wait until machine has come to a complete stop before proceeding with speed change! Speed adjustment: Open the pulley cover to expose the pulleys and drive belts. Loosen the belt tension lock handles. Choose the proper speed for the drilling operation.
- Page 12 SPEED ADJUSTMENT Model: SB-25V RPMs RPMs RPMs RPMs RPMs RPMs RPMs RPMs Pulley RPMs Steps 10hz 20hz 30hz 40hz 50hz 60hz 70hz @ 80hz 90hz 1 - 7 1 - 6 2 - 7 1 - 5 2 - 6...
- Page 13 The proper drill speed for a given drill bit size is as on following table: Material Cast Tool Steel Cast Iron Mild Steel Alum. & Type Steel Copper SURFACE FEET PER MINUTE s.f.m. s.f.m. s.f.m. s.f.m. s.f.m. Drill Dia. Inch REVOLUTIONS PER MINUTE 1/16 2,445...
- Page 14 Installation of drill bits in the chuck: A drill bit with a shaft of at least 1” long should be used to allow correct chuck jaw contact. If shaft length is less than 1” do not insert bit as far into the chuck where it allows jaw contact with drill flutes.
- Page 15 2. MAINTENANCE OF MACHINE MAINTENANCE 1. On a regular basis blow out any dust that may accumulate inside the motor. (Frequency depends on environment the machine is 2. A coat of automotive wax applied to the table and column will help to keep the surface clean.
- Page 16 SB 25V...
- Page 17 PARTS LIST for SB–25 / SB-32 Item Item Description SB-25 SB-32 Description SB-25 SB-32 Base 301040 301041 Spring & Cap 301063 301064 Flange 301042 301043 Motor Pulley 301065 301065 Spring Washer (4x) 13 mm 13 mm Belt 301066 301066 Screw 300999 300999 Screw (4x)
- Page 18 ADDITIONAL PARTS LIST Parts list Item # Part name Part # Qty. Top cover 87377 Drive unit 302704 Name plate emergency stop 301904 Emergency stop button 716538 Back mounting plate 87378 Bracket 87382 Name plate reverse stop forward 302746 Selector Switch 302730 Switch mounting box 87379...
- Page 19 TROUBLESHOOTING GUIDE Problem Possible Cause Remedy Machine does not turn on Not plugged in Plug into proper receptacle Frequency drive has error Clear error by turning off then back on Too long or not correct extension Remove extension cord and plug directly cord into receptacle Emergency stop button is activated...
- Page 20 ELECTRICAL WARNING 1. In the event of a malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This machine is equipped with an electric cord having an equipment grounding conductor. The proper plug must be used that is properly installed and grounded in accordance with all local codes and ordinances.
- Page 21 ELECTRICAL DIAGRAM...
