1. Product information:

Article:
Simple motor-glider with electro drive.
Use: Free flight , for no wind or light wind conditions

2. Material information:

2.1 Material: Pine, Balsa wood, Beech wood
Working:
Joining:
Finish:
2.2 Material: Hard foam
Working:
Joining:
Finish:
3. Tools:
Fretsaw: for all curves and shapes where other types of saw are not suitable.
Note:
Insert blades with teeth facing forward, use a fretsaw board.
PUK saw: Use a PUK saw for all small pieces and dowel
Modelling knife:
Note:
Sanding block:

4. Parts list

No. Quantity Part
1 1 Fuselage
2 2 Motor holder
3 2 Tube holder
4 2 Wing carrier
5 2 Wing holder
6 1 Fin
7 1 Tail fin
8 1 Fuselage tube
9 4 Wing saddle
10 2 Wing LE
11 2 Nose strip
12 1 Woven band
13 2 Edging
14 2 Elastic band
15 1 E-motor R21
16 2 Cable
17 1 Slide switch
18 1 Propellor
19 2 Charging leads
2
Must be sawn, shaped and sanded
Glue
Stain or varnish
Cutting with modelling knife
PVA glue
None needed, acrylic colour possible
Modelling knife for foam
danger do not cut towards yourself- use a steel ruler as a straightedge and
guide. Take care not to cut yourself!!!
use glasspaper and block on flat smooth surfaces .
Poplar plywood
Poplar plywood
Poplar plywood
Pine strip
Dowel
Foam
Foam
Card tube
Foam
Balsa
Balsa
Cotton
Foam
Rubber
Material and description
3x 65 x 300
from plywood 3x 65 x 300
from plywood 3x 65 x 300
5 x 5 x 23 from strip 5x5x200
3x150 dia
3x70x125 from piece 3x210x300
3x100x280 from piece 3x210x300
19,5 dia x 420
3 x 125 x 500 from piece 3x 250 x 500
3x6x500
3x6x500
20x260 from piecet 40 x 400
from hard foam remainder
60x3
24 dia
each 500
19 x 6
130
Pattern
Pattern
Pattern
Pattern
Pattern
offcut
offcut
offcut
Pattern
black and red
