Key
3
5
6
8
Troubleshooting LEDs
Status LEDs indicate network and module status. Figure 5 shows the location of the status LEDs on the LTE module.
Figure 5: Status LEDs
https://answers.alarm.com/?title=ADC/Partner/Installation_and_Troubleshooting/Panels/Interlogix_Simon_XT/Interlogix_Simo...
Information displayed
Performs Phone Test.
Wireless signal strength level and module status or error,
if any. The panel will display bars for the signal level
(zero to five) and a number (2 to 31) followed by the
Mode it is in. For more information on the module status,
see
Potential LTE module
Battery voltage as read by the module, to two decimal
places, and the AC power status (e.g. Battery: 6.79v, AC
Power OK).
LTE frequency used by the module: High = 1700MHz;
Low = 700 MHz.
statuses.
Updated: Wed, 29 Jan 2020 21:50:59 GMT
