Alarm.Com LTE Module Installation Manual page 20

Menu
---- Node ID
---- Mode
---- Setpoints
---- Fan
---- Schedules
---- Update 2WTTS
---- Remove From 2WTTS
https://answers.alarm.com/?title=ADC/Partner/Installation_and_Troubleshooting/Panels/Interlogix_Simon_XT/Interlogix_Simo...
Description
The Z-Wave node id of the Z-Wave thermostat. If 0, then
the Z-Wave thermostat has not been found. You may
need to troubleshoot the Z-Wave network via the Z-Wave
Setup menu. Press "OK" to have the module try to find
the thermostat again.
The Z-Wave thermostat's current mode (Off, Heat, Cool)
The current heating and cooling setpoints of the Z-Wave
thermostat. These are the temperature thresholds that
determine when the heating or cooling unit will turn on.
The current fan mode (Auto, On)
Shows whether the thermostat is running on a schedule
(On), or is using a fixed setpoint. Note that these
thermostat schedules must be set from the Alarm.com
website. Some Z-Wave thermostats allow setting
schedules directly at the thermostat. These built-in
schedules cannot be set or controlled via the website or
via the touch screen (2WTTS).
Press OK to force an update of the thermostat
information shown on the touch screen (2WTTS). Note
that these updates may take several minutes to
complete. To speed up the process, go into System
Programming. This puts the panel in high-speed
communication mode with the touch screen.
To remove the association between the Z-Wave
thermostat and the touch screen (2WTTS). This will hide
the Thermostat page on the 2WTTS.
Updated: Wed, 29 Jan 2020 21:50:59 GMT
20
