L4 - Signal level (zero to 5 bars).
L5 – Flashes errors, if any.
PowerSave Mode
The module just powered up, AC power is down, or AC power was recently restored and the battery is recharging. The
module is fully functional and will go into Connected Mode as soon as a signal needs to be sent. Press and hold [5] for
10 seconds to switch the module into Idle Mode and update the signal level reading. The system will go into Idle Mode
every two hours to check for any incoming messages.
L1 - Inactive.
L2 - Communication with panel.
L3 - Same flashing pattern as L2.
L4 - Inactive.
L5 - Inactive
Connected Mode
The module is currently talking to Alarm.com. The module stays in Connected Mode for at least four minutes after
reporting an event to Alarm.com, unless [5] is pressed and held for 10 seconds, which will cause the module to go back
to Idle Mode.
L1 - Flashes errors, if any.
L2 - Communication with panel.
L3 - Communication with Alarm.com.
L4 - Alternates two seconds on, then two seconds off.
L5 - Inactive.
Sleep Mode
The panel is not connected to AC power, or there is an AC power failure, and the battery level is low. The module will
connect to Alarm.com to send a signal, but will otherwise draw almost no power.
Note: If the LTE module is powered down for a short period of time, buffered messages from Alarm.com may be
received when module power is restored.
