Manage Ports & Devices using Cambrionix Software
5
More productivity, saving you time.
Cambrionix provides three interfaces by which the
TS2-16 can be monitored and managed:

• LiveViewer

• Cambrionix API
• Command Line Instructions
LiveViewer
5.1
LiveViewer is an App that can be downloaded from
https://cambrionix.com. Once downloaded and
installed on the host computer, LiveViewer allows
you to switch the ports on and off, set the port to
charge only, or to sync mode.
LiveViewer's home page shows the following
information about all the ports:
• Status (attached/disconnected)
• Mode (Charge/Sync/Off)
• Profile (Charging profile)
• Duration (how long the device has been
attached)
• End time (time the battery reaches a threshold
(full) level
• Current (instantaneous charge current in mA)
• Energy (present energy rate in Wh)
Tick boxes adjacent to each port symbol allow
that port mode to be changed. When the port is
in Sync mode, only instantaneous current can be
monitored through LiveViewer. When the port is in
Charge mode, the charge profile, instantaneous
current, energy rate, duration of charge and end
time are displayed.
In addition to individual port information and
control, LiveViewer displays the TS2-16 rail voltages,
time since switched on, total instantaneous current
and power, and temperature.
Full instructions on LiveViewer are available on our
website.
