Specifications

7
TS2-16
Input Voltage:
Input Current:
Input Frequency:
Input Connection:
Output Voltage:
Output Current:
Output Power:
Output Power (Total):

Certifications

8
• Independently safety tested by the Underwriters
Laboratory (UL) under file #E346549
• CE Tested and marked
• CB Certificate
• FCC Part 15 Tested and marked
• RoHS Compliant
Thunderbolt and the Thunderbolt logo are
trademarks of Intel Corporation in the U.S and/or
other countries.

Safety Guidelines and Precautions

9
Please read and understand these
guidelines prior to installation or use.
The TS2-16 has ESD, over-voltage, over-current
and over-temperature protection. However, to use
the equipment safely you should follow all local
regulations relating to the use of electrical
equipment and note that:
10
100 ~ 250 Vac
3.5A @ 115 VacA
47 ~ 63 Hz
C13
5.2V
2.4A Max per Port
12W Max per Port
200W Maximum
Input/Output Connectors: 16 x USB Type-A,
Ambient Operating
Temperature Range:
Relative humidity:
Dimensions (approx.):
Approximate weight:
• China CCC certification
• Japanese PSE certification (pending)
• Complies with the latest EN60950 safety
requirements for ITE
• Housed within a UL94-V0 specification fire
enclosure
• Failure to install and operate the equipment
in accordance with all local and these safety
guidelines may result in unit failure, electrical
shock and personal injury.
• The plug on the power cord is considered the
"disconnect device" and consequently the mains
outlet should be located near the TS2-16, easily
accessible in case the power supply needs to be
isolated from the mains power.
• If there is a liquid spillage over a ventilation
slot, external data/power connector or product
aperture, remove power from the unit without
contacting the liquid immediately.
2 x Thunderbolt™ 2
0 ~ 35°C
5% to 95%
non-condensing
305 long x 120 wide
x 85 high mm
2.0 kg
