ThunderSync2-16 at a glance

1
16
PORTS
The ThunderSync2-16 (TS2-16) has been designed
for High Speed syncing and data transfer, using an
upstream Thunderbolt™ 2 interface and providing
full 480Mbps output on all 16 ports simultaneously.
The TS2-16 provides 12 Watts of charging power to
each of its 16 USB2.0 ports, allowing mobile devices
to be charged safely and reliably. Using Cambrionix
software all ports can be controlled to allow
charging and/or data transfer while monitoring
important port and device information.
With an integral power supply, the TS2-16 can
charge attached USB devices without using a local
computer and our intelligent charging algorithm
allows almost any device to be charged at its
optimum rate (up to 2.4A per port). The firmware
can be updated to allow new charging profiles
to be added, ensuring the TS2-16 can charge the
latest devices.
When a local (host) computer is attached, the
host can control operation of the ports using our
software. Devices can be charged, synchronised
and monitored through Cambrionix's LiveViewer
App, the Application Programming Interface (API)
4
20
Gbps
Thunderbolt™
to USB 2.0
12
Watts (2.4 A)
per port
or Command Line Instructions. Cambrionix's
free monitoring and control software can be
downloaded from (https://cambrionix.com/login).
Further information on our software is provided
below.
The TS2-16 is fully compliant with High Speed
USB2.0, allowing data transfer at up to 480Mbps
per port when connected to a local computer
through a Thunderbolt™ 2 port. Multiple TS2-16 can
be connected to a single host computer to allow
up to 96 USB2.0-compliant devices to be charged
and sync'd simultaneously. It can also be used with
a Thunderbolt™ 3 Type-C host computer with the
use of an adaptor.
What's included
These items are required to use your TS2-16 and
are included in the box:
• The TS2-16 unit (see Figure 1 below)
• A mains cable appropriate for the country
of use
Optional 0.5m, 2.0m Thunderbolt™ 2 cables are
available to purchase separately.
[
2 programmable
LEDs per port
[
Thunderbolt™ Host
& Expansion Ports
[
Power Input Connector
[
Power Switch
SW Control
&
Monitoring
]
]
]
]
Figure 1
TS2-16 connections
