Fuse allocation
204
No. Consumer
10 Central control unit
11 Central control unit
12 Central control unit
13 Central control unit
14 Power windows (automatic reversing feature)
15
®
ESP
16 Interior lighting
17 Immobiliser
18 Electrical exterior mirror
19 Brake lamps
20 Cruise control, radio, belt warning
21 Not smart electric drive: central control unit, fuel
pump, injection
22 Rear window wiper
23 smart electric drive only: power supply control
unit
24 ‑
25 Power supply control unit
26 Radio
27 Daytime driving lamps
28 12 V socket, cigarette lighter
29 Power supply control unit
30 Forward collision warning
31 Rear fog lamps
32 Radio, central control unit
33 Tail lamps, front foglamps, hazard warning lamp
button, locking button, headlamp range control,
power windows, licence plate lighting, radio,
control unit for heating or climate control system,
cruise control, limiter, parking aid button, pro-
gram selector button, tailgate release, Lane Keep-
ing Assist camera, automatic start/stop system
button
34 Power supply control unit
35 Headlamps, daytime driving lamps
, transmission control unit
Current Colour cod-
ing
20 A Yellow
15 A Blue
10 A Red
15 A Blue
30 A Green
5 A Brown
10 A Red
3 A Violet
5 A Brown
10 A Red
15 A Blue
15 A Blue
15 A Blue
40 A Orange
‑ ‑
30 A Green
20 A Yellow
5 A Brown
15 A Blue
5 A Brown
15 A Blue
‑ ‑
15 A Blue
25 A Cyan
25 A Cyan
25 A Cyan
