Fuse Allocation - SMART fortwo coupe Owner's Manual

Bulb
Side turn signal lamps
Licence plate lighting
Interior lighting
Tail lamps
Bulb
Tail lamp and brake lamp
Rear foglamp

Fuse allocation

No. Consumer
1 Starter motor
2 Power steering control unit
3 Multifunction lever
4 Airbag
5 Transmission control unit
6 Instrument cluster
7 Horn, alarm system
8 Power supply control unit
9 Power supply control unit
Type Bulb
WY 5 W Reversing lamp
W 5 W Turn signals
W 5 W
Type
P21 5 W
P21 W
Fuse allocation
Type
W 16 W
PY 21 W
Current Colour cod-
ing
5 A Brown
5 A Brown
5 A Brown
5 A Brown
25 A Cyan
10 A Red
15 A Blue
10 A Red
10 A Red
203
