Part Number
0000-8G-N03
Package Contents
Snap Head Screw (Qty. 4)
Plastic Washer (Qty. 4)
U-Nut (Qty. 4)
0
Before Installation
A. Area to be covered by mask must be clean. It is recommended that you wash and wax vehicle prior to installation.
B. Both vehicle and mask must be completely dry prior to installation. If moisture under mask is allowed to dry on
vehicle, paint may cloud.
C. Any repainted surfaces in contact with mask must be allowed to cure completely. Consult paint manufacturer or
repair facility if you are not sure.
1
Install Hood Cover
A. With hood open, stretch hood cover (A)
onto hood, pulling each side one or two
inches at a time, until corners fit snugly.
Install hooks on ends of straps (B,C)
into corresponding holes on underside
of hood. Pull evenly on ends of
adjustable straps (B) until tight. Secure
loose ends in elastic loops.
Genuine Accessories
Installation Instructions
Front Mask
Hood Cover (Qty. 1)
Front End Cover (Qty. 1)
A
C
2
1
3
B
Page 1 of 4
Applicable Models:
2010 CX-9
Tools Required
Stubby Phillips
Screwdriver
Scissors
AS 090-M11415cma1209
Advertisement
Related Manuals for Mazda 0000-8G-N03
Summary of Contents for Mazda 0000-8G-N03
- Page 1 Page 1 of 4 Genuine Accessories Installation Instructions Applicable Models: Part Number Front Mask 2010 CX-9 0000-8G-N03 Package Contents Tools Required Stubby Phillips Screwdriver Hood Cover (Qty. 1) Snap Head Screw (Qty. 4) Plastic Washer (Qty. 4) U-Nut (Qty. 4) Scissors Front End Cover (Qty.
- Page 2 Page 2 of 4 Remove wheel well fasteners Install wheel well hardware A. Using stubby phillips screwdriver, remove upper and lower plastic fasteners along front edge of both front A. In both front wheel wells, lift wheel well liner to reveal wheel wells corresponding to snaps on mask.
- Page 3 Page 3 of 4 Install upper attachments Install upper attachments A. On driver’s side of vehicle, attach clips (H) to back edge of air intake grille. Repeat on opposite side. A. On driver’s side, insert small pads (J) into space at center below headlight.
- Page 4 If adjustment is necessary, adjust the hood cover by adjusting the hood cover straps. Refer to step 1. C. Use Mazda Vinyl/Leather Protectant (or equivalent) to preserve color and finish. B. If mask should flap due to high speed or wind conditions, adjust or remove mask completely.
