Specifications
Read Dev ID code
Conformity Level
More Follows
NextObjectID
Number of Objects
Object ID
Object Length
Object Value
Object ID
Object Length
Object Value
Object ID
Object Length
Object Value
4.9
Messages
Depending on adjustable events, various messages can be sent from the device. The
following message types are supported:
· Sending of E-Mails
· SNMP Traps
· Syslog messages
E-Mail messages
E-Mail messages are triggered by the following events:
· Turning on the device
· Switching of the Power Ports
· Loss / return of voltage
· Exceeding of the max / min values of attached sensors
· State change of digital sensor input ports
· Exceeding of max / min values of the measured power consumption
· Condition change of overvoltage protection
SNMP Traps
SNMP Traps are system messages that are sent via the SNMP protocol to different re-
cipients. SNMP traps are triggered by the following events:
· Switching of the Power Ports
· Exceeding of the max / min values of attached sensors
· State change of digital sensor input ports
· Exceeding of max / min values of the measured power consumption
· Condition change of overvoltage protection
Syslog messages
Syslog messages are simple text messages that are sent via UDP to a syslog server.
Under Linux, normally a syslog daemon is already running (eg. syslog-ng), for Mi-
89
Expert Power Control 8032
1 Byte
0x01
1 Byte
0x01
1 Byte
0x00
1 Byte
0x00
1 Byte
0x03
1 Byte
0x00
1 Byte
n1
n1 Bytes
"Company Id"
1 Byte
0x00
1 Byte
n2
n2 Bytes
"Product Id"
1 Byte
0x00
1 Byte
n3
n3 Bytes
"Product Version"
© 2020 GUDE Systems GmbH
