Operating
tivated. This is a security setting in delivery to avoid accidentally locking
a SIM card with the wrong code.
· Log in on the web interface.
· Switch to Configuration / GSM / SIM.
· Here the button "Enable GSM" is set to "No", that is the GSM module is
turned off. Set the button to "yes", then press the button "Apply" to trans-
mit the data to the EPC NET GSM.
· Wait some minutes, until the device has logged into the GSM. You can
see the status change from the Signal Tower indicator LED on the dis-
play or in the web interface.
GSM Status LED's
The GSM status LED's displays different states of the GSM module.
Signal Tower indicator off
GSM module is deactivated.
Signal Tower indicator on
GSM module activated.
Signal Strength Indicator
· 0 bars - no signal
· 2 bars - approx. 30%
· 4 bars - approx. 70%
· 6 bars - approx. 100%
2.4.1

SMS

2.4.1.1

SMS Commands

Description of the SMS format to send commands to the device:
Format
%[cmd-name] [param 1] [...] [param N]
[param x]
{param x}
If activated, a port code or master code will be required. Entering these codes is initi-
ated by p (for Port code) or

2.4.1.1.1 Port: Query Port State

Format
%port state [portnumber]
Command:
Request of status of Output Port 1, Portcode 1111
%port state 1 p1111
Answer:
Hostname: ENC-2191
Output Port state: Port 1 is Off
25
Expert Power Control 8032
{param 1} {...} {param N}
= mandatory parameter
= optional paramater
m (for Master code).
{Portcode/Mastercode}
