Specifications
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} port set {port_num}
extsensor {port_num} {sen_type} {sen_field}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} port show
extsensor {port_num} {sen_type} {sen_field}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} state set {OFF=0|ON=1|
DISABLED=2}
extsensor {port_num} {sen_type} {sen_field}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} state show
extsensor period set {24H=0|12H=1|2H=2|1H=3|
30MIN=4}
extsensor period show
extsensor beeper set {OFF=0|ON=1}
extsensor beeper show
gsm
gsm enabled set {OFF=0|ON=1}
gsm enabled show
gsm pin set "{pin_num}"
gsm pin show
gsm phonenum set "{phone_num}"
gsm phonenum show
gsm admin sms set "{phone_num}"
gsm admin sms show
gsm admin sms enabled set {OFF=0|ON=1}
gsm admin sms enabled show
gsm admin email enabled set {OFF=0|ON=1}
gsm admin email enabled show
gsm admin email set "{email_addr}"
gsm admin email show
gsm dtmf sms pin enabled set {OFF=0|ON=1}
gsm dtmf sms pin enabled show
gsm dtmf sms master pin set "{pin_num}"
gsm dtmf sms master pin show
gsm phonebook check set {OFF=0|ON=1}
gsm phonebook check show
gsm freecall enabled set {OFF=0|ON=1}
gsm freecall enabled show
gsm admin only set {OFF=0|ON=1}
gsm admin only show
gsm sms response set {OFF=0|ON=1}
gsm sms response show
gsm sms error set {OFF=0|ON=1}
gsm sms error show
gsm sms signal set {OFF=0|ON=1}
gsm sms signal show
gsm port name set {OFF=0|ON=1}
gsm port name show
gsm sms autosync set {OFF=0|ON=1}
gsm sms autosync show
gsm call voice enabled set {OFF=0|ON=1}
gsm call voice enabled show
gsm call dtmf enabled set {OFF=0|ON=1}
gsm call dtmf enabled show
gsm phonebook {1..20} name set "{name}"
gsm phonebook {1..20} name show
gsm phonebook {1..20} phonenum set
"{phone_num}"
gsm phonebook {1..20} phonenum show
gsm phonebook {1..20} port set {port_num}
gsm phonebook {1..20} port show
gsm phonebook {1..20} action set {NONE=0|
GSM_TOGGLE=1|GSM_ON=2|GSM_OFF=3|
GSM_RESET=4|GSM_ONOFF1S=5|
GSM_ONOFF5S=6|GSM_OFFON1S=7|
GSM_OFFON5S=8}
gsm phonebook {1..20} action show
Expert Power Control 8032
shows Port for Power Port Switching actions
sets Port state for Power Port Switching actions
shows Port state for Power Port Switching actions
sets sensor Min/Max measurement period
shows sensor Min/Max measurement period
enables beeper sensor alarms
shows if beeper sensor alarms are enabled
enters cmd group "gsm"
activates the built-in GSM module
shows if the built-in GSM module is enabled
sets PIN and switches the PIN request on
shows the PIN of the SIM card
sets the phone number of the SIM card
shows the phone number of the SIM card
sets phone number for SMS status changes
shows phone number for SMS status changes
enables status changes sent via SMS
shows if status changes via SMS are enabled
enables status changes sent via email
shows if status changes via email are enabled
sets status email recipient address
shows status email recipient address
enables necessary pin for port changes
shows if pin is needed for port changes
sets master pin for port changes
shows master pin for port changes
only allow access to calls that correspond to
phonebook entries
shows if phonebook change enabled
enable functions associated with incoming phone
numbers
show if freecall enabled
only allow caller actions from the admin
phonenum
show if caller actions limited to admin phoennum
send a SMS respone for every SMS cmd
show if a SMS respone is sent for every SMS cmd
send a error SMS for a defective incoming SMS
show if error SMS are sent for defective incoming
SMS
send status messages when signal quality
changes
shows if status messages are sent for signal qual-
ity changes
enable that complete port names are sent via
SMS
show if complete port names are sent
get date and time from GSM after power-up
show if autosync is enabled
enable voice samples when a call is coming in
show if voice samples are enabled
allow DTMF tones in voice steering
show if DTM tones are enabled
set name for phonebook entry
show name for phonebook entry
set number for phonebook entry
show number for phonebook entry
set power port num for freecall actions
set power port num for freecall actions
set freecall action
show freecall action
6
6
6
78
