Device Description
A signaling via E-Mail, Syslog or SNMP trap occurs only once during operation, ex-
actly at the moment in which the protection fails. In addition, at the start up of the
device a message is generated, when the overvoltage protection is not active.
1.6

Technical Specifications

Interfaces
Network connectivity
Protocols
GSM Modem
Sim Card (only EPC
Power Supply
Overvoltage Protection
· single peak current for 20/80us pulse
· max. clamping voltage 20/80us pulse,
Ipk = 100 A
Environment
· Operating temperature
· Storage temperature
· Humidity
Case
Measurements
Weight
1.6.1

Electrical Measurement

typical fault tolerances for Ta=25°C, I=1Arms...16Arms, Un=90Vrms...265Vrms
11
Expert Power Control 8032
(only EPC 1292)
1292)
1 x Ethernet port (RJ45)
1 x Serial connector (D-SUB, RS232)
1 x Mains supply (IEC C20, max.16 A)
8 x Load outputs (IEC C13, max. 16 A)
2 x RJ45 for external sensor
10/100 MBit/s 10baseT Ethernet
TCP/IP, HTTP/HTTPS, SNMP
v1/v2c/v3,
SNMP traps, Syslog, E-Mail (SMTP)
Triband GSM Module (900/1800/1900
MHz)
Mini-SIM
internal power supply (100-240 V AC / -
15% / +10%, 50-60 hz)
20 mm / 250 J varistor disk (300V AC)
10000 A
775 V
0°C - 50 °C
-20°C - 70 °C
0% - 95% (non-condensing)
powder coated, galvanized steel sheet
19" (inches), 1 Rack Unit, (Depth 195
mm)
approx. 2.9 kg (8032)
