8039 SIP Video Intercom
Installation & Configuration
Order Codes
8039
Document 90-00075
11/27/2019
Page 1
FW Version 2.0.1
SIP Video Intercom
Algo Communication Products Ltd
4500 Beedie St Burnaby BC Canada V5J 5L2
www.algosolutions.com
8039 SIP Video Intercom (FW version 2.0.1)
support@algosolutions.com
(604) 454-3792

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8039 and is the answer not in the manual?

Questions and answers

Related Manuals for Algo 8039

Summary of Contents for Algo 8039

  • Page 1 8039 SIP Video Intercom (FW version 2.0.1) 8039 SIP Video Intercom FW Version 2.0.1 Installation & Configuration Order Codes 8039 SIP Video Intercom Document 90-00075 Algo Communication Products Ltd (604) 454-3792 11/27/2019 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com...

  • Page 2: Table Of Contents

    8039 SIP Video Intercom (FW version 2.0.1) Table of Contents IMPORTANT SAFETY INFORMATION...................... 3 OVERVIEW..............................6 ....................6 NTRODUCTION ’ 1.5)........6 COMPARED TO THE PREVIOUS FIRMWARE V SETUP AND INSTALLATION........................7 & T ...............7 ETTING TARTED UICK NSTALL ....................8 NSTALLATION ................8...

  • Page 3: Important Safety Information

    If the product is installed beyond the building perimeter or used in an inter-building application, the wiring connections must be protected against over voltage / transient. Algo recommends that this product be installed by a qualified electrician.
  • Page 4 Produkt von einem qualifizierten Elektriker installieren zu lassenv. Sollten Sie die englischen Sicherheitsinformationen nicht verstehen, kontaktieren Sie bitte Algo per Email bevor Sie mit der Installation beginnen, um Unterstützung zu erhalten. Algo kann unter der folgenden E-Mail-Adresse erreicht werden: support@algosolutions.com.
  • Page 5 “sound to air” acoustic testing. WET OR OUTDOOR ENVIRONMENTS The 8039 SIP Video Intercom is intended for indoor or outdoor locations and may be subjected to spray or weather, provided the rear wiring cavity is properly sealed to prevent water ingress.

  • Page 6: Overview

    8039 SIP Video Intercom (FW version 2.0.1) Overview Introduction The 8039 SIP Video Intercom is ideal for secure business entrances, emergency intercom, and gated entrances. The Algo 8039 provides hands-free intercom capability with video, entrance security with door unlock control, rugged weatherproof design, and superior audio performance.

  • Page 7: Setup And Installation

    2. After the boot is complete, press the call button on the 8039 to hear the IP address. (Once the SIP Server field is populated in the 8039 web interface, the call button will contact the preconfigured extension when pressed.)

  • Page 8: Installation

    After boot up, the speaker will beep and the intercom will have obtained an IP address. If there is no DHCP server the 8039 SIP Video Intercom will default to the static IP address 192.168.1.111. Before the 8039 is configured, the call button on the front can be pressed to play the IP address over the speaker.

  • Page 9: Wiring Connections

    Enter the IP address (e.g 192.168.1.111) into a browser such as Google Chrome, Firefox, or Internet Explorer (other than IE9). The web interface should be visible and the default password will be algo in lower case letters. Wiring Connections Network Connection The speaker provides a RJ45 jack for network connection.
  • Page 10 Reset The 8039 SIP Video Intercom can only be reset during a power up. To return all the settings to the factory default for the 8039, wait until all the backlit keys start flashing. Then press and hold the call button until the call button backlight begins a double flash pattern.

  • Page 11: Web Interface Status And Login

    Admin tab after logging in the first time. Web Interface is accessed by entering 8039’s IP Address into the web browse. Important: It is highly recommended to change the default password if the device is directly connected to a public network.

  • Page 12: Status

    The device’s Status page will be available before and after log on. The section can be used to check 8039’s SIP Registration status of the SIP extensions, Call Status, Proxy Status, Extension to Dial, Door Controller status, and general MAC, IP, Netmask, and Date/Time information.

  • Page 13: Web Interface Basic Settings

    The IP address (e.g. 192.168.1.111) or domain name (e.g. myserver.com) of the SIP Server SIP Extension Used to register the 8039 on the SIP Server. Authentication ID May also be called Username for some SIP servers and in some cases may be the same as the SIP extension.

  • Page 14: Basic Settings Tab - Features

    Basic Settings Tab – Features Speaker Volume Select speaker audio level of the 8039 from 1 (lowest) to 10 (highest). Automatic Gain Control (AGC) Normalizes the audio level. This ensures audio level heard at the speaker is always at a consistent level, independent of the phone that is used to answer the call.
  • Page 15 Outbound Ring Limit This feature can be used to set a limit on how long the intercom will ring before timing out. If the call is not answered within this time period, the 8039 will go back to an idle state.

  • Page 16: Basic Settings Tab - Video

    8039 SIP Video Intercom (FW version 2.0.1) Basic Settings Tab – Video Exposure Region Select an exposure calculation region for optimal image rendering. “Spot” method calculates exposure based on the center area of the image. “Full Frame” method uses the entire image to determine the exposure. “Centre Weighted” uses mainly the center area and a fraction of the remaining frame to compute the exposure.
  • Page 17 8039 SIP Video Intercom (FW version 2.0.1) Brightness Increase or decrease image brightness either above or below the default value. Contrast Increase or decrease image contrast either above or below the default value. Sharpness Increase or decrease image sharpness either above or below the default value.
  • Page 18 8039 initiates a call. Select the video capacity as supported by the video phone that will answer the calls. SIP Video Stream This controls the actual video stream sent by the 8039. Use ‘Auto’ mode unless a manual override is required for compatibility with legacy video phones. Maximum Browser Sessions Allows for a limit to be set on the number of separate browser sessions that can be open simultaneously to show the video.

  • Page 19: Basic Settings Tab - Keypad

    Basic Settings Tab – Keypad Dial Mode – Single Number This mode allows the 8039’s “Call” button to dial a pre-configured number, the “Extension to Dial”. There is also an option to allow all the number keys on the keypad to dial this same extension.

  • Page 20: Basic Settings Tab - Door Control

    Basic Settings Tab – Door Control The 8039 contains a relay that can be used for Door Control, or it can be used with the optional 8061 IP Relay Controller (sold separately) for additional door security, as the 8061 can be located inside the building and separate from the public-facing intercom.
  • Page 21 48. Network Door Controller Password Used to authenticate the link between the 8039 and the 8061. Ensure that the two devices have matching passwords. Default password is algo. Note: The Relay Module Password is used solely to secure the link between the 8039 and the 8061.

  • Page 22: Basic Settings Tab - Multicast

    Basic Settings Tab – Multicast Multicast IP Addresses Each 8039 SIP Video Intercom has its own IP address, and shares a common multicast IP and port number (multicast zone) for multicast packets. The 8039 is able to act as a multicast Slave, allowing it to multicast messages from a Master device over the intercom speaker.
  • Page 23 8039 SIP Video Intercom (FW version 2.0.1) Multicast Page Zones The 8039 Video Intercom supports nine “basic” multicast zones. These zones are defined by the multicast IP addresses. Somewhat arbitrarily, these zones are defined below but may be used in other ways.
  • Page 24 8039 SIP Video Intercom (FW version 2.0.1) Multicast Mode (Slave Selected) If Slave mode is enabled the 8039 intercom speaker will activate when receiving a multicast message. Multicast Type - Regular Select “Regular” if receiving multicast from other Algo SIP endpoint(s) and/or multicast-enabled phone(s) that use RTP audio packets.
  • Page 25 25 Polycom Groups configured on the Algo device. If an Algo device is used as a Multicast master, a tone does not have to be set as the Algo master will provide its own tone. Polycom Group Tones can be set in Advanced Settings > Advanced Multicast tab.

  • Page 26: Web Interface Advanced Settings

    DHCP is an IP standard designed to make administration of IP addresses simpler. When selected, DHCP will automatically configure IP addresses for each 8039 on the network. Alternatively the 8039 can be set to a static IP address. VLAN Mode Enables or Disables VLAN Tagging.
  • Page 27 8039 SIP Video Intercom (FW version 2.0.1) VLAN ID Specifies the VLAN to which the Ethernet frame belongs. A 12-bit field specifying the VLAN to which the Ethernet frame belongs. The hexadecimal values of 0x000 and 0xFFF are reserved. All other values may be used as VLAN identifiers, allowing up to 4094 VLANs.

  • Page 28: Advanced Settings Tab - Admin

    Advanced Settings Tab – Admin Password Password to log into the 8039 SIP Video Intercom web interface. You should change the default password algo in order to secure the device on the network. If you have forgotten your password, you will need to perform a reset using the Reset Button in order to restore the password (as well as all other settings) back to the original factory default conditions.
  • Page 29 Log Level Use on the advice of Algo technical support only. Log Method Allows the 8039 SIP Video Intercom to write to external Syslog server if the option for external (or both) is selected. Log Server If “Network” or “Both” is selected this is the address of the Syslog server on the network.

  • Page 30: Advanced Settings Tab - Time

    SIP log file for a registration attempt). The Realms may be the same or different for all the extensions used. SNMP Support Additional SNMP support is anticipated for future, but the 8039 SIP Video Intercom will respond to a simple status query for automated supervision. Contact Algo technical support for more information.

  • Page 31: Advanced Settings Tab - Provisioning

    This will prevent unauthorized re-configuration of the device if DHCP is used. Provisioning allows installers to pre-configure 8039 SIP Video Intercom units prior to installation on a network. It is typically used for large deployments to save time and ensure consistent setups.
  • Page 32 “Provisioning Server”: TFTP (Trivial File Transfer Protocol), FTP, HTTP, or HTTPS. For example, 8039 configuration files can be automatically downloaded from a TFTP server using DHCP Option 66. This option code (when set) supplies a TFTP boot server address to the DHCP client to boot from.
  • Page 33 Intercom with the MAC address specified in the configuration file name. Since all the necessary settings can be included in this file, the 8039 will be ready to work immediately after the configuration file is downloaded. The MAC address of each 8039 SIP Video Intercom can be found on the back label of the unit.

  • Page 34: Advanced Settings Tab - Advanced Audio

    8039 SIP Video Intercom (FW version 2.0.1) Advanced Settings Tab – Advanced Audio Dynamic Range Compression (DRC) If enabled, compresses the dynamic range of page audio to increase loudness. Dynamic Range Compression Gain ‘Dynamic Range Compression’ must be enabled to display this setting. Higher compression gain increases distortion.
  • Page 35 8039 SIP Video Intercom (FW version 2.0.1) Speaker Noise Filter Enables heavy filtering below 145Hz to reduce mains induced noise (fans). Microphone Filter Applies a high-pass filter to the microphone input. Used to reduce audio artifacts like humming or buzzing by filtering out unwanted frequencies.

  • Page 36: Advanced Settings Tab - Advanced Sip

    8039 SIP Video Intercom (FW version 2.0.1) Advanced Settings Tab – Advanced SIP SIP Transportation Which transport layer protocol to use for SIP messages. Setting ‘SIP Transportation’ to ‘TLS’, ensures the encryption of SIP traffic. SIPS Scheme Only visible when ‘SIP Transportation’ set to ‘TLS’. Enabling SIPS Scheme requires the SIP connection from endpoint to endpoint to be secure.
  • Page 37 Backup Server #2 If backup server #1 is unreachable the 8039 SIP Video Intercom will attempt to register with the 2nd backup server. If enabled, the 8039 SIP Video Intercom will always attempt to register with the highest priority server.
  • Page 38 SIP message used to poll servers to monitor availability. Keep-alive Method If Double CRLF is selected the 8039 SIP Video Intercom will send a packet every 30 seconds (unless changed) to maintain connection with the SIP Server if behind NAT.

  • Page 39: Advanced Settings Tab - Advanced Multicast

    RTCP packets. Audio Sync When paging to the 8039 SIP Video Intercom as well as other third party devices, the low latency of the 8039 may cause the audio to lead other devices. By adding Document 90-00075 Algo Communication Products Ltd...
  • Page 40 Slave endpoints. Polycom Slave Tones A tone may be set for any of the 25 Polycom Groups. If using an Algo device as a Multicast master, it is recommended to set the slave tones to “None” to avoid conflicts, as the Algo devices already multicast a tone by default.
  • Page 41 8039 SIP Video Intercom (FW version 2.0.1) Advanced Settings Tab – Snapshot Snapshot Mode Disable or enable the snapshot to be triggered when the call is made. Important: Enabling snapshot mode will disable low-power sleep mode. Image Archiving Frame Rate Choose a frame rate from 1/5 FPS to 5 FPS.
  • Page 42 8039 SIP Video Intercom (FW version 2.0.1) No. of Images Captured After Event Number of images to be captured after the call is made. Min. Time Between Events Ignore upcoming events for the chosen period after a triggering event. Audible Click Play a tone when image is captured.

  • Page 43: Web Interface System

    Restore Configuration File Restore settings from a backup file. Restore Configuration to Defaults Resets all 8039 SIP Video Intercom device settings to factory default values. Download Backup File Saves the device settings (configuration) and all the files in File Manager: certificates, licenses, and tones to a backup zip file.

  • Page 44: Upgrade 8039 Sip Video Intercom Firmware

    How to upgrade 8039 SIP Video Intercom Firmware 1. From the top menu, click on System, then Maintenance. 2. In the Upgrade section, click on Choose File and select the 8039 SIP Video Intercom firmware file to upload. Note that a SFW file must be loaded.
  • Page 45 System Tab - File Manager Uploading custom Ring Tones (WAV Files) Custom WAV files may be uploaded into memory (1 GB) to play on the 8039 speaker. An existing file may also be modified by downloading the original via the links in the web interface, making the desired changes, and then uploading the new version with a different name.

  • Page 46: System - System Log

    System Tab – System Log System log files are automatically created and assist with troubleshooting in the event the 8039 SIP Video Intercom does not behave as expected. Document 90-00075 Algo Communication Products Ltd (604) 454-3792...

  • Page 47: Specifications

    Microphone: Single Wideband. Memory: 1 GByte audio storage. Door Control: Optional Algo 8061 IP Relay Controller or internal relay NO or NC rated 30V 1A. Configuration: Web interface (HTTP or HTTPS) or auto provisioning server. Provisioning: TFTP, FTP, HTTP, HTTPS...

  • Page 48: 8061 Ip Relay Controller

    Door control relay on the 8039 which would require the door strike wires to be run outside the building. The door control feature is activated by a...

  • Page 49: Typical 8039/8061 Setup

    8039 SIP Video Intercom (FW version 2.0.1) Typical 8039/8061 Setup PoE and Relay Connections on back of 8061 IP Relay Controller: 1. Connect the 8061 to the network via an Ethernet cable at the back of the device. Ensure that a PoE port is used for power and that the 8061 is connected to the same subnet and VLAN as the target intercom.

  • Page 50: Configuring The 8061

    Algo website www.algosolutions.com/locator). This tool displays all of the Algo devices available on the network, and their corresponding IP addresses. Note this address down as you will need it when you configure the 8039 for use with this device.

  • Page 51: Fcc Compliance Statement

    8039 SIP Video Intercom (FW version 2.0.1) FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
