Coolant - Triumph Rocket 3 TFC 2020 Owner's Handbook Manual

Instantaneous Fuel Consumption
An indication of the fuel consumption
at an instant in time. If the motorcycle
is stationary, --.- will be shown in the
display area.
Range to Empty
This is an indication of the predicted
distance that can be travelled on the
remaining fuel in the tank.
Reset
To reset the average fuel consumption,
press and hold the joystick centre.
Note
After refuelling, the fuel gauge and
range to empty
be updated only
motorcycle. Depending on the riding
style, updating could take up to five
minutes.

Coolant

The coolant information tray menu
indicates the temperature of the engine
coolant.
12.4
°
C
Temperature OK
1. Coolant symbol
2. Coolant information tray
3. Coolant temperature gauge
information
while riding
1
15:53
A
H
N
Coolant
68°C
C
2
The coolant temperature is shown
in the information tray with a status
message. The coolant temperature is
also shown in a gauge in the right hand
side display section. The gauge ranges
between C (cold) and H (hot). When the
engine is started from cold the gauge
will show grey bars. As the temperature
increases more bars in the gauge will
be shown illuminated. When the engine
is started from hot the gauge will show
the relevant number of illuminated bars,
dependant on engine temperature.
With the engine running, if the coolant
temperature becomes dangerously high,
the high coolant temperature warning
light on the display will be illuminated
will
and a message will be shown in the
the
information tray.
Stop the engine immediately if the
high coolant temperature warning
light illuminates.
the engine until the fault has been
rectified.
Severe engine damage will result from
running the engine when the high
coolant temperature warning light is
illuminated.
3
Instruments
Caution
Do not restart
39
