Instruments

Tachometer

Never allow engine speed to enter the
red zone as severe engine damage
may result.
The tachometer shows the engine
speed in revolutions per minute - rpm
(r/min). At the end of the tachometer
range there is the red zone.
Engine speeds in the red zone are above
maximum recommended engine speed
and are also above the range for best
performance.
12.4
°
C
1
1. Engine speed (rpm)
The tachometer is shown in the main
circle section of the instrument display
when the Chronos theme is selected.
30
Caution
3
Trip 1
0 0 0 7 4 8 2
mi

Fuel Gauge

The fuel gauge indicates the amount of
fuel in the tank.
1 2
12.4
°
C
+
mpg
1. Fuel gauge
2. Low fuel warning light
3. Low fuel information tray
The fuel gauge is shown in the left
hand panel when the Chronos theme is
selected.
The range to empty and instantaneous
fuel consumption is shown in the right
hand panel when the Fuel menu is
selected.
With the ignition switched on, a filled
line in the fuel gauge indicates the fuel
remaining in the fuel tank.
The gauge
intermediate fuel levels between an
empty and full fuel tank.
The low fuel warning light will illuminate
when approximately 4 litres of fuel is
remaining in the tank and you should
refuel at the earliest opportunity.
A low fuel warning message will appear
in the information tray. Press the
joystick centre to acknowledge and hide
the low fuel warning.
15:53
A
N
OK
Low Fuel
1/3
42.2 38
RANGE
mi
3
markings indicate
