Hach Flo-Dar Sensor Basic User Manual page 8

Figure 1 System overview
1 Flo-Dar sensor with optional surcharge velocity
sensor
2 Flow logger or controller
4.4 Product components
Make sure that all components have been received. Refer to
missing or damaged, contact the manufacturer or a sales representative immediately.
8 English
3 Mounting frame
4 Non-hazardous environment
Figure 2 and Figure 3. If any items are
