Chapter 1 General Information

1.1 Introduction

The IPC-610 is a PC/AT-compatible computer designed for industrial applications. This rugged, all-steel
chassis meets the EIA RS-310C 19" rackmount standard. The unit includes a 14-slot PC-bus compatible
passive backplane, and a more efficient switching power supply in a single fan-cooled chassis.
The passive backplane configuration of the IPC-610 minimizes downtime, simplifies troubleshooting,
makes upgrading easier and allows for a more efficient system package. All electronic components are
modular in design and can be easily serviced. The IPC-610 accommodates most plug-in cards, including
CPU, video, disk controller, and I/O interface cards. They can be conveniently installed and replaced
from the top of the unit.
The IPC-610 will withstand shock, vibration, dust, and a wide range of operating temperatures in harsh
industrial environments. The chassis is positively pressurized by two filtered push-pull cooling fans to
exclude dust and dirt. A lockable door protects drives and switches from tampering and foreign
particles.
Note: There are several special versions of the IPC-610 also available.
The IPC-610-MB-XXX is designed to use the popular and
inexpensive "Baby AT" and "ATX" form-factor motherboards.
The IPC-610-XXX-250X is designed to use the popular "ATX" 250 W
power supply.
The IPC-610-XXX-300R is designed to use the popular 300 W
redundant power supply.
For more detailed information, contact your local dealer.

1.2 Specifications

General
• Construction: Heavy-duty steel
• Disk drive capacity: Two half-height 5¼" drives and one 3½" drive accessible from the front panel;
and two 3½" HDDs inside the chassis
• Cooling system: One 32 CFM cooling fan (flow-out) on the rear panel for the power supply, another
86 CFM fan (flow-in) on the front panel with an air filter
• Keyboard connector: Pre-wired DIN connectors on both front and rear panels
• Controls: Reset, power on/off and keyboard-lock switches
• Indicators: LEDs for power on/off, HDD and keyboard-lock
• Speaker: One 8 Ω, ¼ watt speaker
• Weight: 19 kg (41.8 lb)
• Paint color: Pantone 415C (light gray)
• Dimensions (W x D x H):
482 x 502 x 177 mm (19" x 19.8" x 7")
