SECTION 1.
D GENERAL
• Frequency coverage :
<For ID-880H>
Version TX
U.S.A. 144–148, 430–450
1
CHN 136–173.995* ,
3
400–469.995*
EXP
KOR 144–146, 430–440
AUS 144–148, 430–440
TPE 144–146, 430–432
1 2
* Guaranteed 144–148 MHz only, * Guaranteed 430–450 MHz only,
3 4
* Guaranteed 430–440 MHz only, * Not Guaranteed
<For ID-E880>
Version TX
EUR 144–146, 430–440
144–146, 430–434
ITA
435–438
EUR-1 144–146, 430–440
1
* Guaranteed 144–146 MHz only, *
3
* Guaranteed 430–434 MHz only, *
5
* Not guaranteed
• Type of emission
• Number of memory channels
• Frequency resolution
• Operating temperature range
• Frequency stability
• Power supply requirement
• Current drain
(at 13.8 V DC: approx.)
Transmit
Receive
(simultaneous receive)
• Antenna connector
• Dimensions
(proj. not included)
• Weight
(approx.)
All stated specifications are subject to change without notice or obligation.

SPECIFICATIONS

:
(unit: MHz)
RX
1
118–173.995* ,
2
230–549.995* ,
4
810–823.990* ,
4
849–868.990* ,
4
894–999.990*
1
118–173.995* ,
3
230–549.995* ,
4
810–999.990*
144–146, 430–440
144–148, 430–440
144–146, 430–432
(unit: MHz)
RX
1
118–173.995* ,
2
230–549.995* ,
5
810–999.990*
118–173.995* 1 ,
3, 4
230–549.995* * ,
5
810–999.990*
144–146, 430–440
2
Guaranteed 430–440 MHz only
4
Guaranteed 435–438 MHz only
: FM, AM , DV
(Receive only)
: 1052 (incl. 50 scan edges and 2 calls)
‡ ‡ ‡ ‡
: 5 , 6.25 , 8.33 , 10, 12.5, 15 , 20, 25,
30, 50, 100, 125, 200 kHz
‡
Selectable depending on the operating
frequency band.
: –10°C to +60°C; +14˚F to +140˚F
: ±2.5 ppm
(–10°C to +60°C)
: 13.8 V DC ±15%
:
at 50 W VHF: 11.5 A*
UHF: 12.5 A*
* 8.0 A (at 25 W) only for the TPE version
standby 0.9 A
max. audio 1.2 A
: SO-239
(50 Ω)
: 150(W) × 40(H) × 199.2(D) mm
5 29 ⁄ (W)×1 9 ⁄ (H)×7 27 ⁄ (D) in
32 16 32
: 1.3 kg; 2 lb 14 oz
(not incl. cable)
D TRANSMITTER
• Modulation system
FM
DV
(DIgital)
• Output power
• Max. frequency deviation
• Spurious emissions
• Microphone connector
D RECEIVER
• Receive system
• Intermediate frequencies
• Sensitivity
(amateur bands only)
FM
(12 dB SINAD)
DV
(BER 1%)
†
• Squelch sensitivity
(threshold)
†
• Selectivity (typical)
Wide
Narrow
DV
• Spurious and image rejection
†
• AF output power
(at 13.8 V DC)
• Ext. speaker connectors
†
Guaranteed 144–146 or 144–148 MHz and 430–440 or 440–450 MHz ranges only.
1 - 1
:
Variable reactance frequency modulation
GMSK reactance frequency modulation
: 50/15/5 W*
(approx.)
*25/15/5 W only for the TPE version.
: ±5.0 kHz
(wide)
±2.5 kHz
(narrow)
: Less than –60 dB
: 8-pin modular
(600 Ω)
: Double conversion superheterodyne
: 1st: 46.35 MHz, 2nd: 450 kHz
:
Less than 0.18 μV
Less than 0.35 μV
: Less than 0.13 μV
:
More than 10 kHz/6 dB
Less than 30 kHz/60 dB
More than 6 kHz/6 dB
Less than 20 kHz/60 dB
More than 50 dB
†
: More than 60 dB
: More than 2.0 W
at 10% distortion with an 8 Ω
load
1
: 3-conductor 3.5 (d) mm ( ⁄
")/8 Ω
8
