• CONTROL UNIT
LCD CONTRAST ADJUSTER
RESET IC
(IC2)
CPU CLOCK (9.8304 MHz)
FRONT CPU
(IC4)
+5V REGULATOR
(IC8)
(Q15)
(X1)
2 - 2
BACKLIGHT DRIVER
(Q1)
+5C REGULATOR
(Q16)
LCD DRIVER
(IC7)
