Introduction
The HSA 800 and HSA 802 are available in a variety of surface
finishes, including black anodized metal, brushed aluminum,
brushed brass, polished aluminum, and polished brass.
Features
•
UL listed
•
Easy access to connectors and controls
•
Durable mechanical movement and latching mechanism
•
Available in a variety of surface finishes
•
Includes a variety of RJ-45 connector bezel colors: black,
red, blue, orange, gray, white, ivory, yellow, and green
•
Compact size
•
Easy installation of two or four double-space Extron
AAPs
•
RJ-45 (CAT 5/6) network and data connections
•
Grounded AC plug(s)
www.camboard.de
1-4
Surface Access Products • Introduction
CAMBOARD Electronics
Tel. 07131 911201
Fax 07131 911203
2
Chapter Two
Installation
Installation Overview
Preparing the Routing Template
Preparing the Table and Mounting the Enclosure
Cabling and Installing the AAPs
ce-info@camboard.de
Surface Access Products • Introduction
Bezels
