Maintenance and Modifications, cont'd
Adjustment
Screws
Figure 3-6 — Location of level adjustment and
locking screws
4.
Carefully turn the three adjustment screws on the
underside of the top panel to level the top panel with the
flange.
5.
Tighten the six screws that you loosened in step 3.
6.
Reinstall the surface mount enclosure. See Removing and
Replacing the Enclosure, steps 11 through 19.
www.camboard.de
3-12
Surface Access Products • Maintenance and Modifications
CAMBOARD Electronics
Locking Screws
Locking
Screws
(1 concealed)
Tel. 07131 911201
Fax 07131 911203
Surface Access Products
A
A ppendix A
Reference Information
Routing Template and Replacement Parts
ce-info@camboard.de
Specifications
Part Numbers
Included Parts
Interface Accessories
Top Plate Dimensions
