2.0 How to operate the Level Control
30°
6
B
Programming of detection range and time delay
before operation
1. Press "Power on". The green lamp is on. The lifting
2. Use button (B) – choose the requested settings,
3. Press the button (B) 3 seconds. The lamp of the
4. Use the arrows (up/down) to change the value.
5. After 10 seconds the unit will store the value and
Due to safety the lowering movement will stop
automatically at a fork height of approx. 200 mm.
The photocell can be turned 30° to the right or
left.
NOTE! The photocell must point across the
pallet.
equipment can start lifting/lowering automatically.
detection range or time delay before operation (the
lamp of the chosen setting lightens)..
chosen setting flashes, when programming is
possible. The setting value is shown in the display.
Detection range:
Time delay before operation: 00 s (min) to 25 s (max)
return to normal operations.
0,1m (min) to 2,0 m (max)
