Dimensions - mikroElektronika SmartGLCD User Manual

Hide thumbs
Table of Contents

Advertisement

14.3mm
(0.52")
9.7mm
(0.44")
1.6mm
(0.06")
15.61mm (0.61")
Tolerance +/- 0.3mm
140mm (5.51")
134mm (5.28")
2.54mm (0.10")
128mm (5.04")
Page 25
30mm (1.18")
12.57mm (0.50")
7mm (0.28")
