Operation and Description of Function Settings
*
{Note}
36
Setup and Calibration - continued
20. Humidity Indicator (optional) available only Model 16 - this comes from the
factory pre-calibrated. If further calibration is required, use a reliable separate
device and compare readings. If an adjustment is required, edit the reading as
needed. Here again, the "offset" is for troubleshooting purposes and is not
editable.
21. Access Code (security) - an access code is available for added security if
needed. The access code is a four (4) digit number. This number is entered by
using the numbers of the Subject buttons.
For example:
If the access code were "1234", you would press the Current Conditions button,
Set Temperature-Timer button, Outputs Temperatures button, and the Feed
Clock button when asked for the access code.
From the factory, the Access Code is "1111". This is a special number which
causes the control to not ask you for the access code when you first press the Edit
button.
If you decide to define your own access code, it is done in this area of the setup
screen. Answer "yes" to the question, "change access code", and respond to the
screen's question.
If you later decide you don't want to use an access code, you simply change the
access code back to "1111". If you forget your access code, call Chore-Time. It
is certainly recommended that you write down your access code in a safe place.

MS Board Dip Switch Positions

1. Manual Switch position on first board — one board being used
2. Manual Switch position on second board — two boards being used
3. Manual Switch position on third board — three boards being used
New controls will come from the factory pre-set. This information is
provided only when a replacement board is used.
Chore-Tronics Model 16 & 8 Control
ON
1 2 3
ON
1 2 3
ON
1 2 3
MT1554A 9/9/98 1/6/99
