Introduction to Control
*
{Note}
16

How to Maneuver in the Viewing Screen

• The procedures below give a brief overview on the use of the Navigation Buttons
and the Edit Buttons.
• For this example we will be looking at the Setup and Calibration Screen. (Button
12 on the Control front panel).

Using the Navigation Buttons

1. Press BUTTON 12.
Setup and Calibration screen for viewing appears (Figure 1).
Figure 1. Setup and Calibration Screen.
At this point you can move from line to line by pushing the DOWN ARROW or
the UP ARROW. This will cause the text to either scroll up or down one line at
a time.
2. Press the DOWN ARROW once.
The text will scroll one line (Figure 2). If you push the UP ARROW once the
text will scroll back to the previous line.
Figure 2. Setup and Calibration Screen.
The LEFT and RIGHT arrow keys are only functional in the
Edit Mode.
See following page on the use of the Edit Buttons.
Chore-Tronics Model 16 & 8 Control
MT1554A 9/9/98 1/6/99
