Introduction to Control
14

Viewing Screen

The viewing screen has a display which can show 8 lines, each containing 40
characters. This is the area that will display the requested information when a subject
button is pressed. The viewing screen will always remain lit. When other subjects are
not shown, the Current Conditions screen will be displayed

Navigation Buttons

These buttons allow you to scroll up and down in those few screens that have more
information than will fit on the screen. When HOLDING DOWN an up or down
arrow button, this will activate "auto repeat", which accelerates the scrolling process.
The left and right arrows are used only when you are in the Edit Mode (explained
below) and will move a cursor to an editable (changeable) position. This will
highlight the area you want to change.

Edit Buttons

When the button labeled Edit is pressed and you are looking at a screen that has
editable fields, a cursor will appear. With the Navigation Buttons, you can move the
cursor to the position on the screen you want to edit. By pressing the "+" or "–"
button, it will change the numerical value up or down, or if you are changing text (i.e.
"yes" or "no") it will select the possible text choices. These buttons also have "auto
repeat" which will accelerate the changing of numbers.
