Initial Setup
10

Types of Outputs

EXH FAN, TUN FAN, COOL AND STIR FAN

(Relay contacts close, supplying power to the equipment on temperature rise).
1

HEAT ZONE

(Relay contacts close, supplying power to the equipment on temperature fall).
4
Chore-Tronics Model 16 & 8 Control
2 3
5
Key Description
1 Output Off
2 Fan Off (temp falling)
3 Fan On (temp rising)
4 Output On
5 Temperature Increasing
6 7
8
Key Description
1 Output Off
4 Output On
6 Heat On (temp falling)
7 Heat Off (temp rising)
8 Temperature Decreasing
4
MT1553-01 4/98
1
MT1553-02 4/98
MT1554A 9/9/98 1/6/99
