Feed Clock; Light Clock - Chore-Time Chore-Tronics Model 8 User& Installer's Manual

Operation and Description of Function Settings
*
{Note}
22

Feed Clock

2
1. Number of Events - here you determine the number of feeding events you want
by placing a number (up to 24) in this position. Whatever you choose will then
show on the screen so you can put in the start and run times.
2. Start Time - here you enter the start time that you want that particular feeding
cycle to begin. This can be shown in twelve or twenty-four hour time (see Setup
screen, button 12).
3. Run Time - this is where you enter the run time for the feeding cycle. This is
done in hours, minutes, and seconds. If a time segment is not needed such as
seconds, then place zeros in these positions.
A run time of all zeros will prevent an event from happening.

Light Clock

The light clock functions in the same manner as the Feed Clock
Chore-Tronics Model 16 & 8 Control
Figure 9. Feed Clock Screen
1
3
MT1554A 9/9/98 1/6/99
