Chore-Tronics Model 16 & 8 Control
*
{Note}
The white text with black background
designates those areas that can be edited to
the individual growers specifications.
When viewing the actual Control Display,
the text will be black with a shaded green
background.
MT1554A 9/9/98

Using the Edit Buttons

• This example gives you a brief summary on how to use the Edit Buttons in
conjunction with the Navigation Buttons to edit values.
• For this example we will be looking at the Setup and Calibration Screen.
(BUTTON 12 on the Control front panel).
1. Press BUTTON 12.
Setup and Calibration screen for viewing appears (Figure 3).
Figure 3. Setup and Calibration Screen.
2. Press the EDIT button.
(If a screen comes up asking you for an "Access Code", enter it at
this time. If more information is needed please turn to the operation
section page 36.) This activates the cursor and allows you to edit
certain settings. Figure 4 shows what the screen looks like.
• Notice that the settings are highlighted when they can be edited.
3. Press the (+) or (–) buttons to edit the House #.
The (+) key will increase the value and the (–) key will decrease the value.
Figure 4. Setup and Calibration edit Screen.
Introduction to Control
17
